Handheld Two Way Radio TC-V77
Model Number: TC-V77
Key Specifications / Features
China Two Way Radio Manufacturer Truest provides Handheld Two Way Radio with FM radio, TC-V77, All calls, group calls, Meet the U.S.A Military Standards.
Contact Supplier
Detail Information
Main Features:
1. FM radio.
2. Voice guide.
3. Voice encryption (Selection).
4. Flashlight.
5. DTMF.
6. ANI code.
7. H/L power.
8. All calls, group calls.
9. Emergency alarm.
10. Inspection.
11. Monitor.
12. Stun and kill.
13. Battery save.
14. VOX.
15. TOT.
16. Busy channel lockout.
17. Wired cloning.
18. PC programming.
Technical Specifications:
General:
1. Frequency Range: FM:87-108MHZ, VHF:136-174MHZ, UHF:350-390MHZ, 400-470MHZ, 480-520MHZ.
2. Frequency combination: Phase lock loop frequency synthesize.
3. Memory Channels: 128 Channels.
4. Operating Voltage: DC 7.4V.
5. Channel Spacing: 12.5/25KHz.
6. Battery Capacity: 1200MAH (Li-ion battery).
7. Frequency Stability: ±2.5PPM.
8. CTCSS/DSC: CTCSS:50, DCS:105.
9. Antenna Impedance: 50Ω.
10. Operating Temperature: -10℃ to +60℃.
11. Weight (approx.): 190g (Except battery and antenna).
12. Dimension (approx.): 110×61×34mm (Except Antenna).
Transmitter (Testing under TIA/EIA-603 standard):
1. Output Power: ≤ 5W.
2. Modulation Mode: 16K￠F3E.
3. MAX.Frequency Deviation: ≤±5.0KHz.
4. Frequency Stability: ±5ppm.
5. Spurious Radiation: ≤60dB.
6. Residual Modulation: ≤-35dB.
7. Modulation Distortion: ≤5% (300-3000Hz).
8. FM Noise: ≤-40dB.
9. Audio Distortion: ≤5%.
10. CTCSS Frequency Deviation: 0.75KHz±50Hz.
Receiver (Testing under TIA/EIA-603 standard).
1. Sensitivity: ≤0.20uV.
2. Operating Bandwidth: ≥±7KHz.
3. Squelch Sensitivity: ≤0.15uV.
4. Frequency Stability: ±5ppm.
5. Adjacent channel selectivity: ≥60dB.
6. Spurious Rejection: ≥60dB.
7. Intermodulation Rejection: ≥60dB0.
8. FM Noise: ≤-45dB.
9. Audio Power: ≥600mW.
10. Audio Distortion: ＜5%.
1. FM radio.
2. Voice guide.
3. Voice encryption (Selection).
4. Flashlight.
5. DTMF.
6. ANI code.
7. H/L power.
8. All calls, group calls.
9. Emergency alarm.
10. Inspection.
11. Monitor.
12. Stun and kill.
13. Battery save.
14. VOX.
15. TOT.
16. Busy channel lockout.
17. Wired cloning.
18. PC programming.
Technical Specifications:
General:
1. Frequency Range: FM:87-108MHZ, VHF:136-174MHZ, UHF:350-390MHZ, 400-470MHZ, 480-520MHZ.
2. Frequency combination: Phase lock loop frequency synthesize.
3. Memory Channels: 128 Channels.
4. Operating Voltage: DC 7.4V.
5. Channel Spacing: 12.5/25KHz.
6. Battery Capacity: 1200MAH (Li-ion battery).
7. Frequency Stability: ±2.5PPM.
8. CTCSS/DSC: CTCSS:50, DCS:105.
9. Antenna Impedance: 50Ω.
10. Operating Temperature: -10℃ to +60℃.
11. Weight (approx.): 190g (Except battery and antenna).
12. Dimension (approx.): 110×61×34mm (Except Antenna).
Transmitter (Testing under TIA/EIA-603 standard):
1. Output Power: ≤ 5W.
2. Modulation Mode: 16K￠F3E.
3. MAX.Frequency Deviation: ≤±5.0KHz.
4. Frequency Stability: ±5ppm.
5. Spurious Radiation: ≤60dB.
6. Residual Modulation: ≤-35dB.
7. Modulation Distortion: ≤5% (300-3000Hz).
8. FM Noise: ≤-40dB.
9. Audio Distortion: ≤5%.
10. CTCSS Frequency Deviation: 0.75KHz±50Hz.
Receiver (Testing under TIA/EIA-603 standard).
1. Sensitivity: ≤0.20uV.
2. Operating Bandwidth: ≥±7KHz.
3. Squelch Sensitivity: ≤0.15uV.
4. Frequency Stability: ±5ppm.
5. Adjacent channel selectivity: ≥60dB.
6. Spurious Rejection: ≥60dB.
7. Intermodulation Rejection: ≥60dB0.
8. FM Noise: ≤-45dB.
9. Audio Power: ≥600mW.
10. Audio Distortion: ＜5%.
