FM Dual Band Two Way Radio TC-6100PLUS
Model Number: TC-6100PLUS
Key Specifications / Features
China FM Dual Band Two Way Radio Manufacturer Truest provides FM Dual Band Two Way Radio, Voice guide, Boot password settings, Busy channel lockout.
Contact Supplier
Detail Information
Main Features:
1. Full VHF/UHF.
2. FM radio.
3. Voice guide.
4. Voice encryption (Selection).
5. Battery indicator.
6. Priority scan.
7. LPD/FRS/PMR shift.
8. Call end tone.
9. Boot password settings.
10. Boot greetings edit.
11. Busy channel lockout.
12. CTCSS/CDCSS.
13. Hight / Low power.
14. PTT ID.
15. VOX.
16. TOT.
17. Wired cloning.
18. PC programming.
1. Full VHF/UHF.
2. FM radio.
3. Voice guide.
4. Voice encryption (Selection).
5. Battery indicator.
6. Priority scan.
7. LPD/FRS/PMR shift.
8. Call end tone.
9. Boot password settings.
10. Boot greetings edit.
11. Busy channel lockout.
12. CTCSS/CDCSS.
13. Hight / Low power.
14. PTT ID.
15. VOX.
16. TOT.
17. Wired cloning.
18. PC programming.
| General Specification | |||
| Frequency Range | VHF: 136-174MHZ UHF: 400-470MHZ, 420-490MHZ PMR: 446-446.093MHZ, LPD: 433.075-434.775MHZ, FRS:462.565-467.712MHZ |
Frequency combination | Phase lock loop frequency synthesize |
| Memory Channels | 128Channels | Operating Voltage | DC7.4V |
| Channel Spacing | 12.5/25KHz | Battery Capacity | 1300MAH（Li-ion battery） |
| Frequency Stability | ±2.5PPM | CTCSS/DSC | CTCSS:50, DCS:107 |
| Antenna Impedance | 50Ω | Operating Temperature | -10℃ to +60℃ |
| Weight (approx.) | 220g (Except battery and antenna) | Dimension (approx.) | 98×53×30mm (Except Antenna) |
| Transmitter（Testing under TIA/EIA-603 standard） | |||
| Output Power | ≤ 5 W (H) /3W (M)/1W(L) | Modulation Mode | 16K￠F3E |
| MAX. Frequency Deviation | ≤±5.0KHz | Frequency Stability | ±5ppm |
| Spurious Radiation | ≤60dB | Residual Modulation | ≤-35dB |
| Modulation Distortion | ≤5%(300-3000Hz) | FM Noise | ≤-40dB |
| Audio Distortion | ≤5% | CTCSS Frequency Deviation | 0.75KHz±50Hz |
| Receiver（Testing under TIA/EIA-603 standard) | |||
| Sensitivity | ≤0.20uV | Operating Bandwidth | ≥±7KHz |
| Squelch Sensitivity | ≤0.15uV | Frequency Stability | ±5ppm |
| Adjacent channel selectivity | ≥60dB | Spurious Rejection | ≥60dB |
| Intermodulation Rejection | ≥60dB | FM Noise | ≤-45dB |
| Audio Power | ≥600mW | Audio Distortion | ＜5% |
| Meet U.S.A Military Standards （MIL-STD-810C/D/E） | |||
