Dual Display Mini FM Radio Transceiver TC-898UV

Main Features:
1. Dual band: 136-174MHz/400-470MHz/245MHz (Receive only).
2. Dual Reception/Dual Display.
3. Voice Compand and Scrambler.
4. Multi silent mode (QT/QTADT/QTXDT), 107 groups, DCS/58 groups CTCSS.
5. DTMF encoding and DTMF decoding.
6. PTT ID（Voice broadcast PTT ID).
7. All calls, group calls and selective calls.
8. Monitor, RX Inhibit, RXTX Inhibit and Emergency Alarm.
9. FM Radio（87.5MHz-108MHz).
10. Scan/Scan add.
11. Channel name edit available.
12. 199 memory channels.
13. High/Low power (10W/4W).
14. APO (Auto Power Off).
15. TOT (Time-out timer).
16. Font Set (Big/Small).
17. VOX (Level adjustable).
18. Busy channel lockout.
19. Keyboard lock (Auto/Manual).
20. Multi scan mode (TO/CO).
21. Channel steps (2.5K/5K/6.25K/10K/12.5K/25K).
22. Wide/Narrow band selection (25KHz/12.5KHz).
23. TX Stop.
24. Talk Around.
25. Beat frequency.
26. Reverse frequency function.
27. 1750Hz burst tone.
28. Four key programmable.
29. Lease Function (can program lease time of the radio at a exact time).
30. Input frequency by using Keypad.
31. Wireless changing frequency.
32. Timepiece.
33. PC software disable frequency input.
34. Passwords for menu functions Set.
35. PTT Times per Minutes Set.
36. All/Function reset.
37. 13.8V DC Power Supply.
38. Size: 120×85×40mm.
39: Connector :Sl-16 female/SO239.

Technical Specifications:

General:
1. TX Frequency: 400 - 470MHz or 136 - 174MHz.
2. RX Frequency: 400 - 520MHz or 136 -174MHz; 200 - 260MHz or 87.5 - 108MHz.
3. Channel Capacity: 199.
4. High/Low Output Power: 4W/10W.
5. Operation Mode: Half-Duplex.
6. Dimension (L×W×H): 120×90×40mm.
7. Weight: 315g.
8. Modulation Limitation: ≤±5KHz.
9. Spurious Radiation: 60dB.
10. TX Current: 1A/1.8A.
11. Frequency Stability: ±2.5PPM.
12. Rx Sensitivity: <0.18μV.
13. Modulation Type: F3E.
14. Audio Power: ≥ 400mW.
