Customized Horizontal Cement Ball Mill, Steel Grinding Balls

Name: Customized Horizontal Cement Ball Mill, Steel Grinding Balls
SKU: BM-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Horizontal cement ball mill supplier offers customized dry grinding ball mill in cement plant, steel grinding balls, max output 160-165 T/H, 260 M3.

Request a quote

Detail Information

Main Spare Parts for Cement Ball Mill:
Wheel, Pinion, Trunnion, Hollow Shaft, Girth Gear, Steel Ball, Ball Mill Diaphragms, Driving Device, Bearings, Liner, Grinding Media

Introduction:
SINOSPARE supplies the cement ball mill from the most powerful national manufacturer who won the national award of "China National Materials Cup" for building materials industry. We can supply ball mills with different specifications and different functions, especially for the ultra-fine grinding of slag, cement and other materials.

The newly designed single-drive and double slide shoe ball mill are installed newly designed slide shoe supporting devices characterized by good lubrication, lightweight and easy maintenance. New "Y" type sealing used in sealing between slide-shoe housing and slide ring are with simple structure and better sealing performance ability.

In order to used uniform specification liner installed inside the cylinder, outer cover type mill gate is designed and installed on ball mills to replace traditional inner mill gate to avoid special work for manhole lining plate as traditional way. More material grinding area and better powder classification efficiency can be achieved by applying newly designed grading type liner system which also with easy maintenance feature.

Material flow volume can be increased by installing adjustable material spreading plate and fixed material spreading plate along with the material spoon in newly designed partition chamber inside the mill which also with easy installation and easy maintenance characteristics.

Specifications:

	Cement Outpit(t/h) Close Circuit/Open Circuit	Effective Volume(m³)	Feed Size(mm)	Rotating Speed(r/min)	Load of Grinding Media(t)	Driving Mode	Main Motor		Main Reducer		Weight(t)
	Cement Outpit(t/h) Close Circuit/Open Circuit	Effective Volume(m³)	Feed Size(mm)	Rotating Speed(r/min)	Load of Grinding Media(t)	Driving Mode	Type	Power	Type	Speed Ratio	Weight(t)
MB1864	(Close)6.5~7	14.76	≤25	23.90	18.5	Edge	JR137-8	210	ZD60-8	4.5	35
MB1870	(Close)7.5	16.44	≤25	23.90	21	Edge	JR138-8	245	ZD60-8	4.5	39.2
MB1875	(Close)7.5~8	17.68	≤25	23.90	22.5	Edge	JR138-8	245	ZD60-8	4.5	40
MB2265	(Close)14~15	21.3	≤25	21.40	31	Edge	JR148-8	380	ZD70-9	5	49
MB2270	(Circuit)15~16	23.1	≤25	21.40	33.4	Edge	JR148-8	380	ZD70-9	5	52
MB2275	16~18/12~14	24.7	≤20	21.40	34	Edge	JR158-8	380	ZD70-9	5	60
MB2295	18~20/14~16	30.3	≤20	21.40	41	Edge	JR1510-8	475	ZDH70-9	5	70
MB22110	18~20/16~17	35.8	≤20	21.40	50	Edge	JR1512-8	570	ZD80	5	92
MB22130	20~22/17~18	42.4	≤20	21.40	53	Edge	YR630-8	630	ZD80	5	106.1
MB2470	17~21/14~17	28.17	≤20	21.40	39	Edge	JR1512-8	570	ZD80	5	72
MB2480	20~23/16~18	32.2	≤20	21.40	45	Edge	JR1512-8	570	ZD80	5	77
MB2490	23~25/18~20	36.2	≤20	21.40	48	Edge	JR1512-8	570	ZD80	5	81
MB24100	26~28/20~22	40.3	≤20	20.91	50	Edge	JR1512-8	570	ZD80	5	111
MB24110	28~30/22~24	43.4	≤20	20.91	58	Edge	JR1512-8	630	MBY630	5	125
MB24120	30~32/24~26	46.5	≤25	21.50	64	Edge	YR800-8	800	MBY710	6.3	126
MB24130	32~35/26~28	49.6	≤25	21.50	70	Edge	YR800-8	800	MBY710	6.3	130.6
MB26100	(Circuit)26~28	45.47	≤20	19.60	66	Edge	YR800-8	800	MBY710	5.6	140
MB26130	37~40/30~32	60.5	≤25	19,11	80	Edge	YR1000-8	1000	MBY710	4.5	158
MB3090	35~40/32~34	58.5	≤20	18.98	85	Edge	YR1000-8	1000	MBY710	5.6	147
MB30110	47~50/38~40	71	≤20	18.98	95	Edge	YR1250-8	1250	MBY(X)800	5.6	165
MB30120	50~52/40~42	73.9	≤20	18.98	103	Edge	YR1400-8	1400	MBY(X)900	6.3	175
MB30130	52~54/42~44	76.8	≤20	18.98	112	Edge	YR1400-8	1400	MBY(X)900	6.3	190
MB32110	(Open)46~48	75.4	≤20	18.20	112	Edge	YR1400-8	1400	MBY(X)900	6.3	213
MB32130	60~62/48~50	88.9	≤20	18.40	123	Edge hollow shaft	YR1600-8	1600	MBY(X)1000	7.1	216
MB32130	60~62/48~50	88.9	≤20	18.40	123	Edge double slide shoe	YR1600-8	1600	MBY(X)1000	7.1	220
MB32140	62~66/50~53	96.5	≤20	18.20	132	Edge	YR1800-8	1800	MBYX1000	6.3	237
MB34110	(Close)60~64	91.2	≤20	18.20	120	Edge	YR1600-8	1600	MBYX1000	6.3	230
MB35115	(Close)62~66 (Close)65~70	99.8 110.8	≤20	17.38	130	Edge	YR1800-8	1800	MBYX1000	6.3	242
MB35130			≤20	17.38	156Max	Edge hollow shaft	YR2000-8	2000	MBYX1000	6.3	258
MB35130			≤20	17.38	156Max	Edge double slide shoe	YR2000-8	2000	JDX-100	6.3	250
M35130			≤20	16.60	156Max	Center hollow shaft	YR2000-8	2000	MFY250A		273
M38120	(Close)70~75	108.5	≤20	7.00	143	Center hollow shaft	YR2500-8	2500	MFY250A		310
M38120	(Close)70~75 (Close)70~75	108.5 133.9	≤25	16.30	143	Center double slide shoe	YR2500-8	2500	MFY250A		320
M38130			≤25	17.00	190 Max	Center double slide shoe	YR2500-8	2500	MFY250A		320
M38130			≤25		190 Max	Center double slide shoe	YR2500-8	2500	JS130-C		330
MB38130			≤25	16.60	190 Max	Single edge and double driving	YRKK800-8	2500	DBS250		325
M40130	(Close)78~82	149	≤25	16.30	192	Center double slide shoe	YRKK900-8	2800	JS140-A		348
M42110	(Close)105~115 125~135/80~85	138 164	≤25	15.80	200	Center double slide shoe	YR2800-8	2800	JS140-A		350
M42130	(Close)105~115 125~135/80~85	138 164	≤25	15.60	230	Center double slide shoe	YRKK1000-8	3550	JS150-B2		380
M42130			≤25			Center double slide shoe	YRKK1000-8	3550	MFY355A		390
M42145	140~145		≤25	16.00	255	Center double slide shoe	YRKK1000-8	3800	MFY400A		405
M46140	(Close)120~135	210	≤25	15.00	285	Center double slide shoe	YR1000-8	4200	JS160-C		485
M50150	(Close)160~165	260	≤25	14.00	350	Center double slide shoe	YRKK1000-8	6000			598
