Custom High Voltage Motor for Cement Plant
Key Specifications / Features
China custom high voltage motor supplier offers custom high voltage motor (3KV, 6KV, 10KV) for cement plant, adjustable speed, outstanding energy saving.
Request a quote
Detail Information
SINOSPARE is the shareholder of LANZHOU SHANGDE ELECTRICAL EQUIPMENT MANUFACTURE CO., LTD. SINOSPARE offers high voltage squirrel cage motor and high voltage induction motor with 3KV, 6KV, 10KV types of HV Motor. The main types of HV Motors we supply covers YKK and YRKK series middle/high voltage three-phase asynchronous motor, YRCT series internal feedback speed regulation motor, YQ series AC traction motor. We also provide spare parts for HV Motors, such as sliding bearing and bearing bush, collecting ring, carbon bush, carbon bush support.
YRCT series internal feedback speed regulation motor is the China Innovation Found Project supervised by the Chinese State Council which first invented by SDE in China. CT series internal feedback speed regulation motor is a pioneer product not only in China but also in global HV motor market. With the speed master device results the characteristic of constant torque with adjustable speed to achieve an outstanding energy saving results. The low-power-consumption YRCT series internal feedback speed regulation motor can be widely used in driving medium-size and large pumps, fans, compressors.
FEATURES & BENEFITS
• Compact Structure
• High Efficiency
• High Reliability
• Easy Installation and Maintenance
APPLICATION
High voltage motors can be used to drive a variety of different machines. Such as compressors, pumps, crushers, cutting machine tools, transportation machinery and other equipment in the mining, machinery industry, petrochemical industry, generators and other industries for the prime driving power.
SPECIFICATION
YRCT series internal feedback speed regulation motor is the China Innovation Found Project supervised by the Chinese State Council which first invented by SDE in China. CT series internal feedback speed regulation motor is a pioneer product not only in China but also in global HV motor market. With the speed master device results the characteristic of constant torque with adjustable speed to achieve an outstanding energy saving results. The low-power-consumption YRCT series internal feedback speed regulation motor can be widely used in driving medium-size and large pumps, fans, compressors.
FEATURES & BENEFITS
• Compact Structure
• High Efficiency
• High Reliability
• Easy Installation and Maintenance
APPLICATION
High voltage motors can be used to drive a variety of different machines. Such as compressors, pumps, crushers, cutting machine tools, transportation machinery and other equipment in the mining, machinery industry, petrochemical industry, generators and other industries for the prime driving power.
SPECIFICATION
| YKK Series High Voltage Motor | ||||
| Center Height(mm) | 355~630 | Power(kW) | 185kW~2500kW | |
| Rated Voltage | 6KV, 10KV | Frequency | 50Hz, 60Hz | |
| Rotor Speed(r/min) | 3000r/min 2-pole, 1500r/min 4-pole, 1000r/min 6-pole, 750r/min 8-pole, 600r/min 10-pole, 500r/min 12-pole |
|||
| Protection Class | IP44,IP55 | Cooling Method | IC611 | |
| Mounting Type | IMB3 | Insulation Class | F | |
| Duty | S1 | |||
| YRKK Series High Voltage Motor | ||||
| Center Height(mm) | 355~630 | Power(kW) | 185kW~1600kW | |
| Rated Voltage | 6KV, 10KV | Frequency | 50Hz, 60Hz | |
| Rotor Speed(r/min) | 1500r/min 4-pole, 1000r/min 6-pole, 750r/min 8-pole, 600r/min 10-pole, 500r/min 12-pole | |||
| Protection Class | IP44,IP55 | Cooling Method | IC611 | |
| Mounting Type | IMB3 | Insulation Class | F | |
| Duty | S1 | |||
| YRCT Series Internal Feedback High Voltage Motor | ||||
| Center Height(mm) | 400~630 | Power(kW) | 200kW~1800kW | |
| Rated Voltage | 6KV, 10KV | Frequency | 50Hz, 60Hz | |
| Rotor Speed(r/min) | [528r/min~1491r/min 4-pole, 395r/min~994r/min 6-pole] for 6KV [660r/min~1492r/min 4-pole, 395r/min~992r/min 6-pole] for 10KV |
|||
| Protection Class | IP44,IP55 | Cooling Method | IC611 | |
| Mounting Type | IMB3 | Insulation Class | F | |
| Duty | S1 | |||
| YQ Series Traction Motor | ||||
| Model | YQ-37 | YQ-45 | YQ-65 | YQ-110 |
| Power(kW) | 37kW | 45kW | 45kW | 110kW |
| Rated Voltage | 400V | 400V | 250V | 400V |
| Rated Torque | 460Nm | 568.4Nm | 634Nm | 1425Nm |
| Rated Current | 68A | 79A | 190A | 193A |
| Insulation Class | IP55 | |||
| Rotor Speed(r/min) | 757r/min | 756r/min | 978r/min | 767r/min |
| Cooling Method | IC08 | |||
| Mounting Type | IMB3 | IMB3/IMB20 | IMB3/IMB20 | IMB20 |
| Frequency | 50Hz/60Hz | |||
