Steel Plate Shot Blasting Machine, Automatic, Compact
Model Number: JX-RCS-02
Key Specifications / Features
Steel Plate Shot Blasting Machine Manufacturer Offers Blasting Machine For Steel Plates, Sheets And Strips, Automatic, Compact, Simple Operation.
Detail Information
Characteristics
| Automatic | Compact Design | Simple Operation |
Description
Steel Plate Shot Blasting Machines for Profiling are designed and produced by adopting the advantages of similar products from both within the country and abroad. Boasting state-of-the-art speeds to remove surface contamination, scale and other impurities from the surface.
Application
1. Structural Steel.
2. Mill Scale Removal.
3. Profiling.
4. Paint Preparation.
Details
1. Main Blast Cabinet with Inspection Door.
2. Blast Wheel Units with Drive Mechanism.
3. Abrasive Circulation Unit.
4. Bucket Elevator Unit.
5. Abrasive Separation/Cleaning System with Storage Hopper.
6. Dust Collector with Cleaning Mechanism.
7. Roller Conveyor System at Inlet & Outlet Side.
8. Control Panel with PLC Control System.
Technology Parameter
| Steel Plate Shot Blasting Machine | |||||||
| Item Type | DX698 | DX6912 | DX6915 | DX6920 | DX6925 | DX6930 | DX6940 |
| Width of work piece(mm) | ≤800 | ≤1200 | ≤1500 | ≤2000 | ≤2500 | ≤3000 | ≤5000 |
| Height of work piece (mm) | ≤300 | ≤400 | ≤500 | ≤600 | ≤600 | ≤650 | ≤650 |
| Cleaning rate (m/min) | 0.5-4 | 0.5-4 | 0.5-4 | 0.5-4 | 0.5-4 | 0.5-4 | 0.5-4 |
| Shot blasting rate(kg/min) | 4*125 | 4*125 | 4*200 | 6*250 | 6*250 | 6*250 | 8*25 |
This machine is not a standard machine, any parameters can be customized according clients’ requirements, so any further information please contact with us, our skilled engineer team will give you the most professional and cost-effective solutions.
