Detail Information

High-Temperature Vitriol Pump
I. Summary for Corrosive Vertical Submerged Pump

submersible-sulfuric-acid-pump-17-780-m3-h-17-50-m-2-5-73-5-kw-01

High-temperature Vitriol Pump

An LSB series high-temperature vitriol pump adopt excellent water power models whose performance is stable, high efficiency and saving power.
With national advanced anti-corrosive materials, the pump parts where liquids pass through are made of XY-21 and XY-31 alloys. The other parts are made of special anti-corrosive casting iron, which makes pump life longer.
The pump widely absorbed the advantages of national and international structure design of vitriol pumps, and has the extended length of its suction pipe, which advances the rigidity of the multi-cell pump, as well as the pump operating level and reliability.
A Remy yielding LSB series high-temperature vitriol pump is high-standard, high-universal, changeable, as well as easy to assemble, disassemble and repairable.

II. Performance Parameter Range for High-temperature Vitriol Pump
Capacity: Q=10~800M3/h
Head: H=15-50m
Temperature:
t<125℃ (98% H2SO4)
t<80℃ (93% H2SO4)
For t<125℃ (density lower than 98%), the IMRC-7special alloy can be used.

III. Performance Parameter Chart for High-temperature Vitriol Pump

Model	Q (M3/h)	H (m)	N (r/min)	η (%)	Power(kw)		Weight (kg)
Model	Q (M3/h)	H (m)	N (r/min)	η (%)	Pa	Per	Weight (kg)
25LSB-40	25	40	2950	60	4.5	11	570
25LSB-40A	23.7	36	2950	59	3.9	11	570
25LSB-40B	22.5	32	2950	58	3.4	11	570
25LSB-40C	21	29	2950	57	2.9	7.5	570
55LSB-40	55	40	2950	66	9.1	22	630
55LSB-40A	52	36	2950	65	7.8	18.5	630
55LSB-40B	49.5	32	2950	64	6.7	15	630
55LSB-40C	46.7	29	2950	63	5.9	15	630
100LSB-40	100	40	2950	68	16	37	740
100LSB-40A	95	36	2950	67	13.9	30	740
100LSB-40B	90	32	2950	66	11.9	30	740
100LSB-40C	85	29	2950	65	10.3	30	740
100LSB-50	100	50	2950	74	18.4	45	735
100LSB-50A	95.3	45.5	2950	73	16.2	37	735
100LSB-50B	90.7	41	2950	72	14	37	735
20LSB-30	20	30	1450	43	3.8	11	730
20LSB-30A	19	27	1450	42	3.3	11	730
20LSB-30B	18	24	1450	41	2.9	7.5	730
20LSB-30C	17	21.5	1450	40	2.5	7.5	730
40LSB-30	40	30	1450	53	6.2	15	980
40LSB-30A	38	27	1450	52	5.4	15	980
40LSB-30B	36	24	1450	51	4.6	11	980
40LSB-30C	34	21.5	1450	50	4.0	11	980
80LSB-30	80	30	1450	65	10	30	940
80LSB-30A	76	27	1450	64	8.7	22	940
80LSB-30B	72	24	1450	63	7.5	22	940
80LSB-30C	68	21.5	1450	62	6.4	18.5	940
200LSB-30	200	30	1450	78	20.9	55	1020
200LSB-30A	190	27	1450	77	18.1	45	1020
200LSB-30B	180	24	1450	76	15.5	37	1020
120LSB-26	120	26	1450	73	11.6	30	945
120LSB-26A	114	23.5	1450	72	10.1	22	945
120LSB-26B	108	21	1450	71	8.7	22	945
120LSB-26C	102	18	1450	70	7.1	18.5	945
200LSB-22	200	22	1450	75	16	37	1020
200LSB-22A	190	21	1450	74	14.7	37	1020
200LSB-22B	180	17.5	1450	73	11.8	30	1020
250LSB-38	250	38	1450	82	31.6	75	1020
250LSB-38A	238	34	1450	81	27.2	75	1020
280LSB-30	280	30	1450	79	29	75	1020
280LSB-30A	266	27	1450	78	25	55	1020
280LSB-30B	252	24	1450	77	21.4	55	1020
360LSB-30	360	30	1450	80	36.8	90	1590
360LSB-30A	342	27	1450	79	31.8	75	1590
360LSB-24	360	24	1450	78	30.2	75	1660
360LSB-24A	342	21.5	1450	77	26	75	1660
360LSB-24B	324	19	1450	76	22.1	55	1660
360LSB-24C	306	17	1450	75	18.9	55	1660
600LSB-30	600	30	1450	82	59.8	132	2665
600LSB-30A	570	27	1450	81	51.7	110	2665
600LSB-30B	540	24	1450	80	44.1	110	2665
600LSB-30C	510	21	1450	79	36.9	90	2665
780LSB-30	780	30	1450	75	85	200	3000
780LSB-30A	740	27	1450	74	73.5	185	3000
780LSB-30B	702	24.3	1450	73	63.6	160	3000
780LSB-30C	663	21.7	1450	72	54.4	132	3000
