Name: Reciprocating Plunger Metering Pump, 186-16800 lph, 6-500 Bar, 11kW
Brand: www.shinjovalve.com
SKU: SJ-MP-10
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Detail Information

High-Performance High Flow Reciprocating Plunger Metering Pump J-T
Capacity range 186-14000lph, 6-500bar.

J-T series plunger metering pump is designed for flow and high-pressure dosing with high performance. The Max pressure can up to 500 bars. The liquid end is coated ceramic from SS316 piston. The plunger packing seal is PTFE compressed by SS316 gland ring to grantee the high pressure and for extended life with minimal leakage. J-T pump is widely used in power plant, petroleum, chemical industry, mining, shipbuilding, light industry and etc.

Features:
1. Flow rate can be adjusted via unique adjusting mechanism from 0-100%.
2. The adjustment can be carried when the pump is in operation or at stop.
3. The metering reproducibility is within ±1% from 30%-100% of the maximum output.
4. Automatic operation is achieved by variable speed drive.
5. Special application for high temperature or low temperature is available with the cooling jacket or heating jacket.

Materials:
1. Pump head: SS304, SS316
2. Pump case: Cast iron
3. Plunger: SS316 coated with ceramic
4. Packing seal: PTFE and SS316 ring
5. Valves: SS304, SS316
6. Valve ball: SS304, SS316, ceramic

Power Supply:
380V 3 phase 50hz on standard, other voltage or 60hz on request; EX-proof motor is available on request.

Parameter Table:

Model	50Hz			60 Hz			Pressure		Plunger Dia. (mm)		Stroke Length (mm)		Power kW(HP)		Inlet&Outlet Size		Connection Size
	Flow (lph)	Flow (gph)	SPM	Flow (gph)	Flow (lph)	SPM	(Bar)	(Psi)
J-T180/50	186	49	93	59	223	112	500	7250		25		80		11(15)		DN15		DN15 WN Flange
J-T220/40	229	61		73	275		400	5800		28
J-T300/30	304	80		96	365		300	4350		32
J-T450/22	455	120		144	546		220	3190		38						DN20		DN20 WN Flange
J-T550/18	556	147		176	667		180	2610		42
J-T780/12	788	208		250	946		120	1740		50
J-T1000/10	1000	264		317	1200		100	1450		55						DN25		DN25 RF Flange
J-T1200/8.5	1200	317		380	1440		85	1233		60
J-T1400/7.5	1420	375		450	1704		75	1088		65
J-T1650/6.5	1665	440		528	1998		65	943		70						DN32		DN32 RF Flange
J-T1900/5.5	1910	505		606	2292		55	798		75
J-T2200/4.8	2200	581		697	2640		48	696		80
J-T2480/4.3	2485	657		788	2982		43	624		85
J-T2800/3.8	2800	740		888	3360		38	551		90						DN40		DN40 RF Flange
J-T3100/3.5	3130	827		992	3756		35	508		95
J-T3460/3.1	3468	916		1099	4162		31	450		100
J-T4200/2.6	4200	1110		1332	5040		26	377		110
J-T5000/2.2	5000	1321		1585	6000		22	319		120						DN50		DN50 RF Flange
J-T5800/1.8	5890	1556		1867	7068		18	261		130
J-T6800/1.6	6830	1804		2165	8196		16	232		140
J-T7800/1.4	7840	2071		2486	9408		14	203		150
J-T8900/1.2	8920	2357		2828	10704		12	174		160						DN65		DN65 RF Flange
J-T10000/1.1	10050	2655		3186	12060		11	160		170
J-T11300/0.9	11330	2993		3592	13596		9	131		180
J-T12600/0.8	12600	3329		3995	15120		8	116		190
J-T14000/0.6	14000	3699		4439	16800		6	87		200						DN80		RF Flange
