Forged Steel Pressure Seal Gate Valve, Class 900, 1500, 2500

Forged Steel Pressure Seal Gate Valve, Class 900, 1500, 2500
Specifications:
ASME Pressure: 900, 1500, 2500 LB.
Sizes: 3/8, 1/2, 3/4, 1-1/4, 1-1/2, 2" ( DN 10, 15, 20, 25, 32, 40, 50 mm ).
Ends: Socket weld, threaded, flanged ends.
Materials: Stainless steel, alloy steel, carbon steel.

Threaded and Socket Weld Ends gate valve
-Dimensions (mm) and Weights (kg):

NPS		1/2	3/4	1	1-1/4	1-1/2	2
L	900~1500Lb	140	140	140	178	178	216
	2500Lb	186	186	186	232	232	279
H(OPEN)		321	321	321	380	414	502
W		160	160	180	200	250	280
Weights	900Lb~1500Lb	11.5	10.8	10.5	19.6	21.0	55.4
	2500Lb	12.3	11.6	10.8	26.0	28.4	60.0

Flanged Ends-Dimensions (mm) and Weights (kg):

NPS		1/2	3/4	1	1/4	1-1/2	2
L(RTJ)	900Lb~1500Lb	216	229	254	279	305	368
	2500Lb	264	273	308	349	384	451
H(OPEN)	900Lb~150Lb	216	250	270	320	350	445
	2500Lb	321	321	321	373	406	495
W		160	160	180	200	250	280
Weights	900Lb~1500Lb	19.6	21.5	25.7	37.8	48.5	99.8
	2500Lb	21.5	24.7	30.4	48.1	58.1	130.0
