CAST IRON JIS 10/16K BALL VALVE
Key Specifications / Features
China Cast Iron Ball Valve Manufacturer Shinjo Supplies Cast Iron Flanged Ball Valve with JIS 10K and 16K flange standard.
Detail Information
SIZE RANGE AND PRESSURE CLASS
Size from 1/2” to 10” (DN15-DN250)
Pressure rating: JIS10K/16K
DESIGN STANDARD
Design and Manufacture : JIS B2002
Face to Face Length standards : JIS B2002 Series 6
Flange Ends Dimensions standards: JIS B2212-1999
TECHNICAL FEATURES
Cast iron body
Split body, side entry design
Floating ball design
Size from 1/2” to 10” (DN15-DN250)
Pressure rating: JIS10K/16K
DESIGN STANDARD
Design and Manufacture : JIS B2002
Face to Face Length standards : JIS B2002 Series 6
Flange Ends Dimensions standards: JIS B2212-1999
TECHNICAL FEATURES
Cast iron body
Split body, side entry design
Floating ball design
|
Main Parts and Materials |
||
|
Number |
Part Name |
Material |
|
1 |
Body |
Cast Iron(FC200 or FCD400) |
|
2 |
Bonnet |
Cast Iron(FC200 or FCD400) |
|
3 |
Ball |
Stainless steel(SUS304) |
|
4 |
Seat |
PTFE |
|
5 |
Stem |
Stainless steel(SUS304) |
|
6 |
Gland Flange |
Cast Iron(FC200 or FCD400) |
|
7 |
Lever |
Ductile iron(FCD 400) |
|
8 |
Nut |
Carbon Steel |
|
9 |
Bolting |
Carbon Steel |
|
Main Dimensions |
||||||
|
Norminal diameter |
10k |
16k |
||||
|
L |
C |
D |
L |
C |
D |
|
|
15 |
108 |
70 |
95 |
108 |
70 |
95 |
|
20 |
117 |
75 |
100 |
117 |
75 |
100 |
|
25 |
127 |
90 |
125 |
127 |
90 |
125 |
|
32 |
140 |
100 |
135 |
140 |
100 |
135 |
|
40 |
165 |
105 |
140 |
165 |
105 |
140 |
|
50 |
178 |
120 |
155 |
178 |
120 |
155 |
|
65 |
190 |
140 |
185 |
190 |
140 |
185 |
|
80 |
203 |
150 |
210 |
203 |
160 |
200 |
|
100 |
229 |
175 |
250 |
229 |
185 |
225 |
|
150 |
394 |
240 |
280 |
394 |
260 |
305 |
|
200 |
457 |
290 |
330 |
457 |
305 |
350 |
|
250 |
553 |
355 |
400 |
553 |
380 |
430 |
