API 600 Cast Steel Globe Valves, Class 300 LB, ASME B16.34, B16.10

API 600 Cast Steel Globe Valves, Class 300 LB, ASME B16.34, B16.10

Model Number: SJ-CSGB-02

Key Specifications / Features

API 600 Cast Steel Globe Valves, Class 300 LB, ASME B16.34, B16.10
Class 300 WCB SS304 ASTM A216 GR WCB
Share:
Contact Supplier

Detail Information

API 600 Cast Steel Globe Valves, Class 300 LB Construction
API 600 Cast Steel Globe Valves, Class 300 LB Structure
API 600 Cast Steel Globe Valves, Class 300 LB Parts
FEATURES & SPECIFICATIONS
OS & Y, Rising Stem Design ASME B16.34/BS 1873
Bolted Bonnet Face to Face ASME B16.10
Conic Disc End to End ASME B16.10
Extended Bonnet for Cryogenic Services End Flange ASME B16.5
Impact Hand wheel Optional BW End ASME B16.25
Gear Optional Test API 598
  Special NACE MR-01-75
STANDARD MATERIALS OF MAIN PARTS
ITEM PART NAME MATERIAL
1 Body ASTM A216 GR.WCB
2 Seat Ring ASTM A105 + Stellite Faced
3 Disc ASTM A105 + 13Cr Faced
4 Disc Thrust Plate ASTM A276 Type 420
5 Disc Nut ASTM A276 Type 410
6 Stem ASTM A182 GR.F6
7 Bonnet Bolt Nuts ASTM A194 GR.2H
8 Bonnet Bolts ASTM A193 GR.B7
9 Gasket Soft Iron + Graphite
10 Backseat Bushing ASTM A276 Type 410
11 Stem Packing Braided Graphite & Die formed Graphite Ring
12 Bonnet ASTM A216 GR.WCB
13 Eye Bolt Pins Carbon Steel
14 Gland ASTM A276 Type 410
15 Gland Flange ASTM A216 GR.WCB
16 Gland Eye Bolts ASTM A307 GR.B
17 Eye Bolt Nuts ASTM A194 GR.2H
18 Yoke Bush ASTM A439 GR.D-2
19 Screw Carbon Steel
20 Hand wheel Ductile Iron
21 Hand wheel Nut ASTM A194 GR.2H
22 Washer Carbon Steel
23 Yoke ASTM A216 GR.WCB
24 Yoke Pan Bolt Nuts ASTM A194 GR.2H
25 Yoke Pan Bolts ASTM A193 GR.B7
26 Bearing Steel
27 Lantern Ring On Request ASTM A276 Type 410
DIMENSIONS & WEIGHTS
Size L/L 1 L2 H W Weight RF
in mm in mm in mm in mm in mm kg
2” 50 10.50 267 11.12 283 14.57 370 8 200 28
2.5” 65 11.50 292 12.12 308 18.66 474 10 250 48
3” 80 12.50 318 13.12 333 17.32 440 10 250 56
4” 100 14.00 356 14.62 371 20.67 525 14 350 82
6” 150 17.50 445 18.12 460 24.41 620 18 450 154
8” 200 22.00 559 22.62 575 35.83 910 22 560 240
10” 250 24.50 622 25.12 638 37.36 949 24 600 319
12” 300 28.00 711 28.62 727 40.63 1032 25 640 632
14” 350 33.00 838 33.62 854 42.91 1090 24 610 975


Note: 1. The technical data is subject to amend without notice, while is subject to the actual product.
      2. If you have any alteration, please note when you ordering.
