Detail Information
Introduction:
Working principle of the main design is permanent magnetic coupling was applied to the centrifugal pump, adopting the advanced new materials made of reinforced polypropylene (PP) pump body materials, design is reasonable, technology is advanced, has the full seal, zero leakage, corrosion resistance and other characteristics, CQF engineering plastic magnetic pump is very compact in structure, elegant appearance, small size, low noise, stable and reliable running, Easy to use and maintain.
Performance Range:
Flow: 1 - 25 m3/h
Delivery Head: 3-32 m
Size.: DN10-DN65 mm
Pump Material: Polypropylene (PP)
Liquid Temperature: ≤60 ℃
Applications:
Widely used in chemical, pharmaceutical, petroleum, petrochemical, food, environmental protection, scientific research institutions, national defense industry and other industries used in pumping acid, alkali, oil, rare and precious liquid, plating liquid, corrosive liquid and circulating water equipment supporting. Especially suitable for all kinds of flammable, explosive, volatile liquid pipeline transportation and pressurization.
Working principle of the main design is permanent magnetic coupling was applied to the centrifugal pump, adopting the advanced new materials made of reinforced polypropylene (PP) pump body materials, design is reasonable, technology is advanced, has the full seal, zero leakage, corrosion resistance and other characteristics, CQF engineering plastic magnetic pump is very compact in structure, elegant appearance, small size, low noise, stable and reliable running, Easy to use and maintain.
Performance Range:
Flow: 1 - 25 m3/h
Delivery Head: 3-32 m
Size.: DN10-DN65 mm
Pump Material: Polypropylene (PP)
Liquid Temperature: ≤60 ℃
Applications:
Widely used in chemical, pharmaceutical, petroleum, petrochemical, food, environmental protection, scientific research institutions, national defense industry and other industries used in pumping acid, alkali, oil, rare and precious liquid, plating liquid, corrosive liquid and circulating water equipment supporting. Especially suitable for all kinds of flammable, explosive, volatile liquid pipeline transportation and pressurization.
| Model | Size | Flow | Head | Motor | Voltage | Material | |
| In (mm) | Out (mm) | (m3/h) | (m) | (kW) | (V) | ||
| 10CQF-3 | 10 | 8 | 1.14 | 3 | 0.01 | 220 | Polypropylene (PP) |
| 14CQF-5 | 14 | 10 | 1.2 | 5 | 0.12 | 220/380 | |
| 16CQF-8 | 15 | 15 | 1.5 | 8 | 0.12 | 220/380 | |
| 20CQF-12 | 25 | 18 | 3 | 12 | 0.37 | 220/380 | |
| 25CQF-15 | 25 | 20 | 5.4 | 15 | 1.1 | 380 | |
| 32CQF-15 | 32 | 25 | 6.5 | 15 | 1.1 | 380 | |
| 32CQF-25 | 32 | 25 | 4.8 | 25 | 1.1 | 380 | |
| 40CQF-20 | 40 | 32 | 10.8 | 20 | 2.2 | 380 | |
| 50CQF-25 | 50 | 40 | 14.4 | 25 | 3 | 380 | |
| 50CQF-32 | 50 | 40 | 13.2 | 32 | 3 | 380 | |
| 65CQF-25 | 65 | 50 | 25 | 25 | 4 | 380 | |
| 65CQF-32 | 65 | 50 | 25 | 32 | 5.5 | 380 | |
