Aluminium Alloy Diaphragm Pump, 0-30 m3/h, 0-50m

Product name: Aluminium Alloy Diaphragm Pump.
Discharge: 0-30 m3/h.
Head: 0-50 m.
Applications: can suck paint, glue, grinding materials, various strong acid, alkali, corrosive liquid, etc.

Features Has good performance and great flow.
Can be soaked in media.
Has simple structure, easy installation and maintenance.
Can convey viscous liquid.
Oil lubricant is not required.
Has convenient and reliable operation.



DISCHARGE (m3/h)-water
Aluminium Alloy Diaphragm Pump

Model	A	B	C	D	E	H1	H2	H3	H	Screw	Flange
										NPT/RC	D1	D2	D3	D	n	g
QBY-10	130	50	220	145	10	39	195	10	270	1/2	-	-	-	-	-	-
QBY-15	130	50	220	145	10	39	195	10	270	1/2	-	-	-	-	-	-
QBY-25	245	160	360	250	12	63	360	36	470	2	-	-	-	-	-	-
QBY-40	245	160	360	250	12	63	360	35	470	11/2 11/4	-	-	-	-	-	-
QBY-50	335	220	540	345	16	88	-	25	720	-	90	50	110	130-130	4	14
QBY-65	335	220	540	345	16	88	-	25	720	-	110	65	130	130-130	4	14
QBY-80	425	250	570	450	18	110	-	32	900	-	125	80	150	160-160	4	18
QBY-100	425	250	570	450	18	110	-	32	900	-	145	100	170	160-160	4	18


More information for aluminium alloy diaphragm pumps

Model

Discharge (m3/h)

Head (m)

Exit pressure (kgf/cm2)

Sucked Lift (m)

Max grain Dia (mm)

Max pressure (kgf/cm2)

Max air consumption (m3/min)

Materials

ZL104

1Cr18 Ni9Ti

HT200

Enhanced Polypr opyene

F4 F46 (EFP)PO

QBY-10

0~0.8

0~50

6

5

1

7

0.3

*

*

*

*

/

QBY-15

0~1

0~50

6

5

1

7

0.3

*

*

*

*

/

QBY-25

0~2.4

0~50

6

7

2.5

7

0.6

*

*

*

*

QBY-40

0~8

0~50

6

7

4.5

7

0.6

*

*

*

*

*

QBY-50

0~12

0~50

6

7

8

7

0.9

*

*

*

/

*

QBY-65

0~16

0~50

6

7

8

7

0.9

*

*

*

/

*

QBY-80

0~24

0~50

6

7

10

7

1.5

*

*

*

/

/

QBY-100

0~30

0~50

6

7

10

7

1.5

*

*

*

/

/
