ASME SA333, ASTM A333 Grade 6 Seamless Steel Pipe

ASTM A333 Gr.6 Seamless steel pipe manufacturer

Steel Grade:
ASTM A333 GR.1, GR.3, GR.6
A335 P1, P2, P12, P11, P22, P5, P9, P91, P92
S355J0H, S355J2H
P195, P235, P265, P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10 A333Gr6

Size:
Outer Diameter: 1/8"-36" (10.3mm-914.4mm)
Wall Thickness: 1.2mm-80mm
Length: Random Length, SRL, DRL (4-14M)
End: plain ends, beveled ends
Surface: Bare, Black,Lightly oiled, Hot dip galvanized,Varnish coating/Anti rust oil, Protective Coatings, 3PE
Packing: Nude, Plastic/steel plugs in both ends, Hexagonal bundles of max. 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips, Plastic caps.


Standard	Steel Grade	Chemical Components							Machanical Property
		C	Mn	Si	Cr	Mo	P	S	Tensile Strength (Mpa)	Yield Strength(Mpa)
ASTM A333	Gr6	≤0.30	0.29~1.06	≥0.10			≤0.025	≤0.025	≥415	≥240
ASTM A335	P1	0.10-0.20	0.30-0.80	0.10-0.50		0.44~0.65	≤0.025	≤0.025	≥380	≥205
	P5	≤0.15	0.30~0.60	≤0.50	4.00~6.00	0.45~0.65	≤0.025	≤0.025	≥415	≥205
	P9	≤0.15	0.30~0.60	0.25~1.00	8.00~10.00	0.90~1.10	≤0.025	≤0.025	≥415	≥205
	P11	0.05~0.15	0.30~0.60	0.50~1.00	1.00~1.50	0.44~0.65	≤0.025	≤0.025	≥415	≥205
	P12	0.05~0.15	0.30~0.61	≤0.50	0.80~1.25	0.44~0.65	≤0.025	≤0.025	≥415	≥220
	P22	0.05~0.15	0.30~0.60	≤0.50	1.90~2.60	0.87~1.13	≤0.025	≤0.025	≥415	≥205
