MSS SP-81 Knife Gate Valve, ASTM A351 CF3M, 150 LB, 40 Inch

Name: MSS SP-81 Knife Gate Valve, ASTM A351 CF3M, 150 LB, 40 Inch
SKU: MFRS-230905-GV-13
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Looking for a reliable Knife Gate Valve? Your search ends here. Explore our Light Seat Replaceable Knife Gate, available in DN1000 (40 inches) size, designed for Class 150 LB applications with a 2-bar rating. These valves adhere to MSS SP-81 standards and are crafted from top-notch materials, including ASTM A182 F55, ASTM A351 CF3M, ASTM A216 WCB, and DI GGG40.

Request a quote

Detail Information

Working Pressure:
DN450 - DN550, 18 - 22 Inch, 8 bar
DN600 - DN650, 24 - 26 Inch, 5 bar
DN700 - DN750, 28 - 30 Inch, 4 bar
DN800 - DN900, 32 - 36 Inch, 3 bar
DN1000, 40 Inch, 2 bar, Class 150 LB

Design Standard: MSS SP-81
Flange Standard: PN10, PN16, 150 LB ,JIS 10K, TABLE E/D
Face to Face: MSS SP-81
Testing Standard: API 598
Transmission: Handle Wheel, electric, pneumatic, hydraulic, sprocket, electro-hydraulic, gear
Main material: ASTM A182 F55, F53, 2205, SS 310, ASTM A351 CF3M, CF3, CF8M, CF8, ASTM A216 WCB, Ductile Iron GGG40
Disc material: ASTM A182 F55, F53, 2205, SS 310, SS 316L, SS 316, SS 304
Sealing material: NBR, NR, EPDM, FKM, Metal to Metal
Packing: PTFE, high water based, rubber packing, graphite
Applicable medium: Applicable for coal in power plant, slag discharge, sewage treatment, food, paper making, medicine and chemical industry, water, Oil, steam, connecting or cutting grout, gold powder, ores, slag, coal, pulp, wood pulp, tailings, fibers, dust, chemicals, sewage treatment, asphalt, fruit juices, cereals, slaughter plant waste and other media.
