Bolted Bonnet Gate Valve, ASME B16.34, 50 Inch, Class 300 LB
Model Number: MFRS-240125-GV-02
Key Specifications / Features
Fabricator of bolted bonnet gate valves in accordance with ASME B16.34 standards. Our valves are crafted from ASTM A216 WCB, providing durability and reliability. With a substantial size of 50 inches and a Class 300 LB rating, these valves are designed for optimum performance.
Detail Information
Standards
Design and Manufacture: ASME B16.34.
Face to Face: ASME B16.10.
Flanged Ends: ASME B16.5.
Test and Inspection: API 598.
Size: 50 Inch.
Pressure Rating: Class 300 LB.
Body/Bonnet: ASTM A216 WCB.
Connect Ends: Flanged.
Trim: 5#.
Bolted bonnet (BB) design.
Full port or reduced port design.
Back seal design.
Rising stem with outside screw and yoke.
Renewable seat or welding seat.
Special Request: locking device (interlock), position indicator, limit switch.
Extended bonnet for cryogenic & underground service is available.
Design and Manufacture: ASME B16.34.
Face to Face: ASME B16.10.
Flanged Ends: ASME B16.5.
Test and Inspection: API 598.
Size: 50 Inch.
Pressure Rating: Class 300 LB.
Body/Bonnet: ASTM A216 WCB.
Connect Ends: Flanged.
Trim: 5#.
Bolted bonnet (BB) design.
Full port or reduced port design.
Back seal design.
Rising stem with outside screw and yoke.
Renewable seat or welding seat.
Special Request: locking device (interlock), position indicator, limit switch.
Extended bonnet for cryogenic & underground service is available.
