ASTM A216 WCB Butterfly Valve, API 609, 36 Inch, 150 LB

Name: ASTM A216 WCB Butterfly Valve, API 609, 36 Inch, 150 LB
SKU: MFRS-230815-BV-03
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Explore our premium selection of Triple Offset Butterfly Valves crafted by a leading manufacturer. These valves are meticulously engineered to adhere to API 609 Cat B and EN 593 standards, boasting a sizable 36-inch size. With a Class 150 LB rating and DN900 specifications, these valves are tailored for handling rigorous applications. Backed by a PN20 pressure rating and furnished with a metal seat featuring a double flange, they ensure steadfast performance. Outfitted with an SS + Graphite Sealing Ring, our valves offer impeccable sealing capabilities. Rely on our expertise for top-tier butterfly valves that consistently deliver exceptional performance.

Request a quote

Detail Information

Structure: Triple Offset
Design Standard: API 609 Cat B, EN 593
Body Material: ASTM A216 WCB
Trim Material: A351 CF8M disc, Laminated Sealing ring SS 316 + Graphite
Face to face: API 609
Test and inspection: API 598
Nominal size: 36 Inch
Nominal class: 150 LB
End Connection: Double Flange-ASME B16.47 Series A
Operation: Gear
Key Features: Metal Seat for high Temperature and various fluids, Low torque, Replaceable seat, Zero Leakage, Excellent control characteristics, Fire Safe

Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 72 Inch (DN50 - DN1800)
Pressure range: Class 150 - 2500 LB
Working temperature: -29℃ - +400℃
Operation: Lever, Gear, Motor, Pneumatic Actuated
End connection: Wafer, Lug, Flanged, BW
