ASME B16.34 Electric Actuated Ball Valve, A105, 48 IN, 600 LB
Model Number: MFRS-240110-TMBV-03
Key Specifications / Features
High-quality Electric Actuated Ball Valve from our factory, designed to meet industry standards including API 6D, ASME B16.34, and ASTM A105. With a robust build, this valve is specifically crafted for heavy-duty applications, boasting a substantial 48-inch size and a Class 600 LB rating. Featuring precision engineering, it operates seamlessly at DN1200 and PN100 levels.
Detail Information
Design standard: API 6D ASME B16.34.
Body material: ASTM A105.
Nominal diameter: 48 Inch (DN1200).
Pressure: Class 600 LB (PN100).
End connection: RF.
Face to face: ASME B16.10.
Working temperature: -29℃ - +200℃.
Mode of operation: Electric actuator.
Test and inspection: API 598.
Product Range
Body Material: Carbon steel, Stainless steel, Alloy steel.
Normal diameter: 2 - 60 Inch (DN50 - DN1500).
End connection: BW, Flanged.
Pressure range: 150 - 2500 LB (PN16 - PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro hydraulic actutor, Gas over oil actuator.
Working temperature: -46℃ - +200℃.
Body material: ASTM A105.
Nominal diameter: 48 Inch (DN1200).
Pressure: Class 600 LB (PN100).
End connection: RF.
Face to face: ASME B16.10.
Working temperature: -29℃ - +200℃.
Mode of operation: Electric actuator.
Test and inspection: API 598.
Product Range
Body Material: Carbon steel, Stainless steel, Alloy steel.
Normal diameter: 2 - 60 Inch (DN50 - DN1500).
End connection: BW, Flanged.
Pressure range: 150 - 2500 LB (PN16 - PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro hydraulic actutor, Gas over oil actuator.
Working temperature: -46℃ - +200℃.
