72 Inch Triple Offset Butterfly Valve, GGG40, EN 593, PN10

Name: 72 Inch Triple Offset Butterfly Valve, GGG40, EN 593, PN10
SKU: MFRS-230815-BV-02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Are you in search of a trustworthy source for soft seat triple offset butterfly valves? Your search ends here. Our company offers an extensive selection of top-quality valves to fulfill your industrial requirements. With a substantial 72-inch size (DN1800) and a PN10 pressure rating, our valves align with both EN 593 and Class 150 LB standards. Designed with double flanges and expertly crafted from durable ductile iron GGG40 material, our valves guarantee optimal performance and long-lasting durability. Enhanced by a GGG40 disc and EPDM O-ring, they deliver exceptional sealing capabilities, making them suitable for a wide range of applications. Rely on us as your preferred supplier of premium butterfly valves.

Request a quote

Detail Information

Design Standard: EN 593
Structure: Triple Offset
Body Material: GGG40
Trim Material: A351 CF8M disc, Laminated Sealing ring SS316+Graphite
Face to face: API 609
Test and inspection: API 598
Nominal size: 72 Inch, DN1800
Nominal class: PN10
End Connection: Double Flange, EN 1092
Operation: Gear
Key Features: Low torque, Zero Leakage, Excellent control characteristics

Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 72 Inch (DN50 - DN1800)
Pressure range: Class 150 - 2500 LB
Working temperature: -29℃ - +400℃
Operation: Lever, Gear, Motor, Pneumatic Actuated
End connection: Wafer, Lug, Flanged, BW
