Stainless Steel Globe Valve, 1/2-2 Inch, 150-2500 LB, API 602
Key Specifications / Features
Stainless Steel Globe Valve Manufacturer: API 602, ASME B16.34, DIN 3202 SS Globe Valves, 1/2-2 Inch, 150-2500 LB, ASTM A182 F304, F316, F304L, F316L, F51.
Class 150 LB Globe Valve
Class 2500 LB Globe Valve
ASME B16.34 Globe Valve
Stainless Steel Globe Valve
1/2 Inch Globe Valve
DIN 3202 Globe Valve
API 602 Globe Valve
2 Inch Globe Valve
ASTM A182 F304 Globe Valve
ASTM A182 F316 Globe Valve
ASTM A182 F304L Globe Valve
ASTM A182 F316L Globe Valve
ASTM A182 F51 Globe Valve
Detail Information
Stainless Steel Globe Valve
Med Stainless Steel Globe Valve is designed and manufactured strictly to International Standards API 602, ASME B16.34, DIN 3202 or Equivalent, a compact but extremely sturdy design for high pressure-temperature service, Solid CoCr alloy wedge (optional) ensures low friction and long service life, packing rings are precompressed to 4000 psi to provide a high integrity seal, for welded bonnet valves, the bonnet is threaded in and torqued to an engineered torque value and the body bonnet joint is strength-welded, offering double protection against leakage. (Body/bonnet threads and strength-weld), fully guided wedge reduces wear on seating surfaces, Optional design available with double packing, leak-off connection, live-loading and a packing blowout for easy removal of old packing.
Med Stainless Steel Globe Valve are with main Features as below:
Size Ranges: 1/2-2 Inch.
Pressure Ratings: ANSI Class 150-2500 LB.
Standards compliance: API 602, ASME B16.34, DIN 3202 or equivalents.
Materials: ASTM A182 F304, ASTM A182 F316, ASTM A182 F304L, ASTM A182 F316L, ASTM A182 F51.
Ends Connections: Screwed, Welded Ends and Flanged (FF, RF, RTJ) to international standards.
OS & Y, Outside Stem and Yoke.
Metal-sealed (API Trim CL1, CL5, CL8, CL10 and etc.).
Optional Locking Device or Stem Extension.
Optional Bolted Bonnet, Welded Bonnet or Pressure Sealed Bonnet.
Optional Direct Mounting to ISO 5211.
Reduce Port.
Med Stainless Steel Globe Valve is designed and manufactured strictly to International Standards API 602, ASME B16.34, DIN 3202 or Equivalent, a compact but extremely sturdy design for high pressure-temperature service, Solid CoCr alloy wedge (optional) ensures low friction and long service life, packing rings are precompressed to 4000 psi to provide a high integrity seal, for welded bonnet valves, the bonnet is threaded in and torqued to an engineered torque value and the body bonnet joint is strength-welded, offering double protection against leakage. (Body/bonnet threads and strength-weld), fully guided wedge reduces wear on seating surfaces, Optional design available with double packing, leak-off connection, live-loading and a packing blowout for easy removal of old packing.
Med Stainless Steel Globe Valve are with main Features as below:
Size Ranges: 1/2-2 Inch.
Pressure Ratings: ANSI Class 150-2500 LB.
Standards compliance: API 602, ASME B16.34, DIN 3202 or equivalents.
Materials: ASTM A182 F304, ASTM A182 F316, ASTM A182 F304L, ASTM A182 F316L, ASTM A182 F51.
Ends Connections: Screwed, Welded Ends and Flanged (FF, RF, RTJ) to international standards.
OS & Y, Outside Stem and Yoke.
Metal-sealed (API Trim CL1, CL5, CL8, CL10 and etc.).
Optional Locking Device or Stem Extension.
Optional Bolted Bonnet, Welded Bonnet or Pressure Sealed Bonnet.
Optional Direct Mounting to ISO 5211.
Reduce Port.
