Forged Bronze Gate Valve, 1/2-2 Inch, 150-800 LB, API 602
Key Specifications / Features
Forged Bronze Gate Valve Fabricator: Metal Sealed Bronze Gate Valves, 1/2-2 Inch, Class 150-800 LB, API 602, ASME B16.34, DIN 3202, OS & Y, Full or Reduce Port.
Request a quote
Detail Information
Forged Bronze Gate Valve
Med Forged Bronze Gate Valve are designed and manufactured strictly to International Standards API 602, ASME B16.34, DIN 3202 or Equivalent, a compact but extremely sturdy design for high pressure-temperature service, Solid CoCr alloy wedge (optional) ensures low friction and long service life, packing rings are precompressed to 4000 psi to provide a high integrity seal, for welded bonnet valves, the bonnet is threaded in and torqued to an engineered torque value and the body bonnet joint is strength-welded, offering double protection against leakage (Body/bonnet threads and strength-weld), fully guided wedge reduces wear on seating surfaces, Optional design available with double packing, leak-off connection, live-loading and a packing blowout for easy removal of old packing.
Med Forged Bronze Valves are with main Features as below:
Size Ranges: 1/2-2 Inch.
Pressure Ratings: ANSI Class 150-800 LB.
Standards compliance: API 602, ASME B16.34 or equivalents.
Materials: B61, B62 and etc.
Ends Connections: Flanged (FF, RF), Screwed, Welded Ends to international standards.
OS & Y, Outside Stem and Yoke.
Metal-sealed-Bronze.
Optional Locking Device or Stem Extension.
Optional Direct Mounting to ISO 5211.
Full Bore or Reduce Port.
Med Forged Bronze Gate Valve are designed and manufactured strictly to International Standards API 602, ASME B16.34, DIN 3202 or Equivalent, a compact but extremely sturdy design for high pressure-temperature service, Solid CoCr alloy wedge (optional) ensures low friction and long service life, packing rings are precompressed to 4000 psi to provide a high integrity seal, for welded bonnet valves, the bonnet is threaded in and torqued to an engineered torque value and the body bonnet joint is strength-welded, offering double protection against leakage (Body/bonnet threads and strength-weld), fully guided wedge reduces wear on seating surfaces, Optional design available with double packing, leak-off connection, live-loading and a packing blowout for easy removal of old packing.
Med Forged Bronze Valves are with main Features as below:
Size Ranges: 1/2-2 Inch.
Pressure Ratings: ANSI Class 150-800 LB.
Standards compliance: API 602, ASME B16.34 or equivalents.
Materials: B61, B62 and etc.
Ends Connections: Flanged (FF, RF), Screwed, Welded Ends to international standards.
OS & Y, Outside Stem and Yoke.
Metal-sealed-Bronze.
Optional Locking Device or Stem Extension.
Optional Direct Mounting to ISO 5211.
Full Bore or Reduce Port.
