Lift Plug Valve, ASME B16.34, Class 150-1500 LB, 2-36 Inch
Model Number: LV 23 SPV 01
Key Specifications / Features
Lift plug valves have a tapered plug that is lifted and lowered to control the flow of fluid through the valve. The plug is held in place by a stem, which is rotated to raise or lower the plug. The ASME B16.34 standard specifies the design and manufacturing requirements for lift plug valves, including the materials, dimensions, pressure ratings, and end connections.
Detail Information
Lift Plug Valve
Specification:
1. Design standard: ASME B16.34
2. Body material: Carbon steel, Stainless steel, duplex stainless steel, Alloy steel, Nickel alloy
3. Pressure range: CLASS 150 - 1500 LB
4. Nominal diameter: NPS 2-36 Inch
5. Mode of operation: Handwheel, Gear box, Electric, Pneumatic, hydraulic device, gas over oil device
6. End connection: RF, RTJ, BW
7. Main features: During the opening process, rotates the stem anticlockwise and lift the tapered plug moving up and pull the plug sealing surface away from the body seat, the clearance between the body and seals allows free movement without friction. Rotates stem further, with the tilt guide mechanism design, the plug will be turned 90°aligning plug port window to valve body bore that valve is fully opened. Because without abrasion between sealing surfaces, the operating torque is very low and the service life is longer. Twin seal plug valves are mainly used in CAA fuel storage plants, harbor refined oil storage plants, manifold plants, etc.
Product Features
1. Valve with orbit lift and rising stem design
2. Valve can be installed at any position
3. During open and close operation, the tilt and turn action, eliminates friction and abrasion between body seat and plug, small operating torque
4. Plug is made by anti-wear material, with rubber lining surface, having an excellent sealing function
5. Valve with bidirectional seal
6. Spring-loaded Stem packing design can be available as per customer request
7. Low emission stem packing according to ISO 15848 requirement is available according to customer request
Specification:
1. Design standard: ASME B16.34
2. Body material: Carbon steel, Stainless steel, duplex stainless steel, Alloy steel, Nickel alloy
3. Pressure range: CLASS 150 - 1500 LB
4. Nominal diameter: NPS 2-36 Inch
5. Mode of operation: Handwheel, Gear box, Electric, Pneumatic, hydraulic device, gas over oil device
6. End connection: RF, RTJ, BW
7. Main features: During the opening process, rotates the stem anticlockwise and lift the tapered plug moving up and pull the plug sealing surface away from the body seat, the clearance between the body and seals allows free movement without friction. Rotates stem further, with the tilt guide mechanism design, the plug will be turned 90°aligning plug port window to valve body bore that valve is fully opened. Because without abrasion between sealing surfaces, the operating torque is very low and the service life is longer. Twin seal plug valves are mainly used in CAA fuel storage plants, harbor refined oil storage plants, manifold plants, etc.
Product Features
1. Valve with orbit lift and rising stem design
2. Valve can be installed at any position
3. During open and close operation, the tilt and turn action, eliminates friction and abrasion between body seat and plug, small operating torque
4. Plug is made by anti-wear material, with rubber lining surface, having an excellent sealing function
5. Valve with bidirectional seal
6. Spring-loaded Stem packing design can be available as per customer request
7. Low emission stem packing according to ISO 15848 requirement is available according to customer request
