ASTM A536 65-45-12 Butterfly Valve, MSS SP-67, 2-12 Inch
Model Number: LV-BTV-20241026-02
Key Specifications / Features
The MSS SP-67 Butterfly Valve, produced in our factory, adheres to MSS SP-67 standards and is constructed from Ductile Iron ASTM A536 Grade 65-45-12. These valves are available in sizes ranging from 2 to 12 inches and can handle pressure ratings between 175 and 300 PSI. Designed with grooved ends for secure connections, they are coated with fusion-bonded epoxy to provide excellent corrosion resistance and enhance overall durability.
Detail Information
MSS SP-67 Butterfly Valves, ASTM A536 65-45-12 Body, Grooved Ends.
Product Item: MSS SP-67 Grooved Butterfly Valve
Body Material: Ductile Iron ASTM A536 Grade 65-45-12
Design Standard: MSS SP-67
Size Range: 2 Inch - 12 Inch
Working Pressure: 300 PSI, 175 PSI, 200 PSI and 250 PSI available upon Request
Top Flange Standard: ISO 5211
Temperature Range: 0°C to 80°C
Connection Ends: Groove to AWWA C606
Coating: Fusion Bonded Epoxy Coating following ANSI/AWWA C550 or Painting upon Request
Stem Drive by Keys, Parallel or Diagonal Square or Flat Head
Product Item: MSS SP-67 Grooved Butterfly Valve
Body Material: Ductile Iron ASTM A536 Grade 65-45-12
Design Standard: MSS SP-67
Size Range: 2 Inch - 12 Inch
Working Pressure: 300 PSI, 175 PSI, 200 PSI and 250 PSI available upon Request
Top Flange Standard: ISO 5211
Temperature Range: 0°C to 80°C
Connection Ends: Groove to AWWA C606
Coating: Fusion Bonded Epoxy Coating following ANSI/AWWA C550 or Painting upon Request
Stem Drive by Keys, Parallel or Diagonal Square or Flat Head
