High Pressure Olet Fittings, 1/8-20 IN, CL3000/6000, Custom

Name: High Pressure Olet Fittings, 1/8-20 IN, CL3000/6000, Custom
SKU: LPF-20250623-OF-02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The High Pressure Olet Fittings Supplier offers a comprehensive range of branch connection fittings, including Weldolet, Sockolet, Threadolet, Nipolet, and Elbolet. These fittings are available in carbon steel, stainless steel, and alloy steel materials, catering to various industrial needs. The size range spans from 1/8 to 20 inches, and they are rated for Class 3000 and 6000 LB pressure classes. These fittings are designed to minimize stress concentrations and provide integral reinforcement, ensuring durability and reliability in high-pressure applications.

Request a quote

Detail Information

Product Name: Customized Olet Fittings, Pipe Olet
Types: Weldolet, Sockolet, Threadolet, Nipolet, Elbolet
Size Range: 1/8-20 Inch, DN6-DN500
Wall Thickness: SCH 40, SCH 80, SCH STD, SCH XS (Class 3000 LB); SCH 160, SCH XXS (Class 6000 LB)
Materials:
Carbon Steel: ASTM A105
Stainless Steel: ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A182 F321
Alloy Steel: ASTM A182 F12, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A350 LF2, ASTM A350 LF3
Application: Olet is designed to connect reinforced fittings. It can replace components such as reducing tees, reinforcement plates, and reinforced pipes. Olet is widely used in high-pressure, high-temperature, large-diameter, and thick-walled piping systems.
