ANSI B36.10 Carbon Steel Pipe, A106 Gr C, 16 Inch
Model Number: LP 14 HRP 08
Key Specifications / Features
China ANSI B36.10 Carbon Steel Pipe Supplier: Hot Rolled Seamless Steel Pipe, Plain Ends, ASTM A106 Gr. C, Schedule 20, 16 Inch, 6-11.8 Meters.
Detail Information
Keywords: Carbon Steel ASTM A106 Gr. C Pipe Seamless 16" x SCH.20.
Name: Pipe.
Quality: 100% Seamless.
Size: 16".
Schedule: SCH 20.
Length: 6-11.8m.
Ends: Plain Ends.
Standard: ANSI B36.10.
ANSI B36.10 Carbon Steel Pipe 16 Inch Parameters:
ANSI B36.10 Carbon Steel Pipe 16 Inch Parameters:
| Size NPS | Wall Thickness | Pipe I.D. | Weight per Foot | Schedule | Section Modulus | Gallon Capacity Per Linear Foot |
| 16 |
0.188 | 15.624 | 31.78 | 36.498 | 9.9696 | |
| 0.203 | 15.594 | 34.28 | 39.298 | 9.9214 | ||
| 0.219 | 15.562 | 36.95 | 42.268 | 9.8807 | ||
| 0.237 | 15.526 | 39.94 | 45.759 | 9.8326 | ||
| 0.250 | 15.500 | 42.09 | 10 | 47.958 | 9.8022 | |
| 0.281 | 15.438 | 47.22 | 53.636 | 9.7233 | ||
| 0.312 | 15.376 | 52.32 | 20 | 59.245 | 9.6447 | |
| 0.344 | 15.312 | 57.57 | 64.787 | 9.5665 | ||
| 0.375 | 15.250 | 62.64 | 30 | 70.261 | 9.4885 | |
| 0.406 | 15.188 | 67.68 | 75.668 | 9.4109 | ||
| 0.438 | 15.124 | 72.86 | 81.008 | 9.3336 | ||
| 0.469 | 15.062 | 77.87 | 86.283 | 9.2566 | ||
| 0.500 | 15.000 | 82.85 | 40 | 91.493 | 9.1800 | |
| 0.562 | 14.876 | 92.75 | 101.720 | 9.0276 | ||
| 0.625 | 14.750 | 102.72 | 111.690 | 8.8765 | ||
| 0.656 | 14.688 | 107.60 | 60 | 116.572 | 8.8021 | |
| 0.688 | 14.624 | 112.62 | 121.519 | 8.7255 | ||
| 0.750 | 14.500 | 122.27 | 130.880 | 8.5782 | ||
| 0.812 | 14.376 | 131.84 | 80 | 140.081 | 8.4321 | |
| 1.031 | 13.938 | 164.98 | 100 | 170.598 | 7.9261 | |
| 1.219 | 13.562 | 192.61 | 120 | 194.599 | 7.5042 | |
| 1.438 | 13.124 | 223.85 | 140 | 220.150 | 7.0274 | |
| 1.594 | 12.812 | 245.48 | 160 | 236.857 | 6.6972 |
