ASTM A182 F304 Plate Flange, 120 LB, 5 Inch
Key Specifications / Features
China Plate Flange Manufacturer: ASTM A182 F304 Plate Flange, Size DN125 (5 Inch), Pressure PN16 (120 LB), EN1092-1 TYPE 01 and RF Ends.
Request a quote
Detail Information
Type: Plate Flange.
Ends: RF.
Material: ASTM A182 F304.
Pressure: PN16 (120 LB).
Size: DN125 (5 Inch).
Standard: EN1092-1 TYPE 01.
| Nominal Pipe Size |
Outside Diameter (OD) |
Inside Diameter (ID) |
Thickness (T) |
Bolt Circle (BC) |
Hole Diameter |
No. of Bolt Holes |
45 Degree Bevel (B) |
Approx. Weight (lbs) |
| 2 | 6.00 | 2.44 | 0.500 | 4.75 | 0.750 | 4 | 0.250 | 3.1 |
| 3 | 7.50 | 3.57 | 0.500 | 6.00 | 0.750 | 4 | 0.250 | 4.6 |
| 4 | 9.00 | 4.57 | 0.500 | 7.50 | 0.750 | 8 | 0.250 | 6.2 |
| 6 | 11.00 | 6.72 | 0.500 | 9.50 | 0.875 | 8 | 0.250 | 7.8 |
| 8 | 13.50 | 8.72 | 0.500 | 11.75 | 0.875 | 8 | 0.250 | 11.2 |
| 10 | 16.00 | 10.88 | 0.500 | 14.25 | 1.000 | 12 | 0.250 | 14.0 |
| 12 | 19.00 | 12.88 | 0.500 | 17.00 | 1.000 | 12 | 0.250 | 20.4 |
