ASTM A105 Orifice Flange, DN80, PN50, SCH 80
Model Number: LF 14 OF 056
Key Specifications / Features
China ASTM A105 Orifice Flange Manufacturer Landee offers ASTM A105 Orifice Flange, ASME B16.36, DN80, PN50, SCH 80, Tongue & Groove Face.
Detail Information
Product: Orifice Flange.
Material: ASTM A105.
Standard: ASME B16.36.
Size: DN80.
Pressure: PN50.
Schedule: SCH 80.
Face: Tongue & Groove.
Material: ASTM A105.
Standard: ASME B16.36.
Size: DN80.
Pressure: PN50.
Schedule: SCH 80.
Face: Tongue & Groove.
.jpg)
| Dimensional Data (inches) | ||||
| Size | A | B | C | D |
| 1 x 1 | 3.500 | .250 | 2.000 | 2.625 |
| 1 1/2 x 1 | 4.000 | .250 | 2.750 | 3.375 |
| 2 x 1 | 5.562 | .250 | 3.500 | 4.125 |
| 3 x 1 | 6.312 | .375 | 4.688 | 5.375 |
| 4 x 1 | 7.062 | .500 | 6.188 | 6.875 |
| 6 x 1 | 8.062 | .500 | 8.000 | 8.750 |
