800LB Carbon Steel Anchor Flange, ASTM A694

Name: 800LB Carbon Steel Anchor Flange, ASTM A694
SKU: LF 14 AF 02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

China Carbon Steel Anchor Flange Producer Landee Offer 800LB Carbon Steel Anchor Flange,API 600, JIS B2239, ASTM A694, 1/2-64 Inch.

Request a quote

Product: ASTM A694 Carbon Steel Anchor Flange.

Type: Anchor Flange.

Material: Carbon Steel, ASTM A694.

Grade: F42, F46, F48, F50, F52, F56, F60, F65, F70.

Standard: API 600, JIS B2239.

Pressure: 800LB.

Size: 1/2-64 Inch (DN15-DN1600).
