Stainless Steel Cryogenic Gate Valve, 150-600 LB, 2-36 Inch
Key Specifications / Features
Stainless Steel Cryogenic Gate Valve Supplier: Low-Temperature Valves, API 600, BS 6364, 150-600 LB, 2-36 Inch, Stainless Steel, Alloy Steel, RF, RTJ, BW.
Detail Information
Cryogenic Gate Valve
Main features: Low-temperature valve is designed with an extended bonnet, which can protect the stem packing and stuffing box area to avoid the effect of low temperature that causes the stem packing to lose its elasticity. An extended area is also convenient for insulation protection. Valves are suitable for Ethylene, LNG plants, air separation plant, Petrochemical gas separation plant, PSA oxygen plants, etc.
Design standard: API 600, BS 6364
Product Range:
1. Pressure range: Class 150-600 LB
2. Nominal diameter: NPS 2-36 Inch
3. Body material: stainless steel, Alloy steel
4. End connection: RF, RTJ, BW
5. Minimum working temperature: -196 ℃
6. Mode of operation: Handwheel, Gearbox, Electric, Pneumatic, hydraulic device, Pneumatic-hydraulic device
Product features:
1. Small flow resistance for fluid, only a small force is required when opening or closing.
2. When the valve is fully opened, the sealing surface suffered small friction from the working medium.
3. With pressure relief hole to prevent abnormal pressure rise in cavity
4. Spring loaded packing can be chosen
5. Low emission packing can be chosen according to ISO 15848 requirements.
6. Valve has medium flow direction requirements.
Main features: Low-temperature valve is designed with an extended bonnet, which can protect the stem packing and stuffing box area to avoid the effect of low temperature that causes the stem packing to lose its elasticity. An extended area is also convenient for insulation protection. Valves are suitable for Ethylene, LNG plants, air separation plant, Petrochemical gas separation plant, PSA oxygen plants, etc.
Design standard: API 600, BS 6364
Product Range:
1. Pressure range: Class 150-600 LB
2. Nominal diameter: NPS 2-36 Inch
3. Body material: stainless steel, Alloy steel
4. End connection: RF, RTJ, BW
5. Minimum working temperature: -196 ℃
6. Mode of operation: Handwheel, Gearbox, Electric, Pneumatic, hydraulic device, Pneumatic-hydraulic device
Product features:
1. Small flow resistance for fluid, only a small force is required when opening or closing.
2. When the valve is fully opened, the sealing surface suffered small friction from the working medium.
3. With pressure relief hole to prevent abnormal pressure rise in cavity
4. Spring loaded packing can be chosen
5. Low emission packing can be chosen according to ISO 15848 requirements.
6. Valve has medium flow direction requirements.
