Pig Launcher & Receiver, Class 150-2500, 3-56 Inch
Model Number: LD 16 PLR 03
Key Specifications / Features
China Pig Launcher & Receiver Manufacturer Landee offers Steel Pig Launcher & Receiver, Class 150-2500, 3-56 Inch, up to 35 Mpa, for oil, gas and water.
Detail Information
Type: Pig Launcher & Receiver.
Material: Carbon Steel, Stainless Steel, Monel.
Class Rating: Class 150 to Class 2500.
Size: 3 inch to 56 inch.
Design Pressure: technical up to 35Mpa.
Test Pressure: Hydrotest pressure is 1.3-1.5 times of the design pressure and air-tight test
pressure is the same as the design pressure.
Corrosion allowable: 2mm-3mm or based on customer's requirements.
Seismic intensity: 8 degree.
Applicable medium: crude oil, finished petroleum oil (gasoline,diesel),gas, water.
Option of Pig Signalers available.
Quick Opening Closures with Safety Interlocks.
Third party classification society approved.
Design codes include ASME VIII DIV. I & ASME B31.3, GB150.
Material: Carbon Steel, Stainless Steel, Monel.
Class Rating: Class 150 to Class 2500.
Size: 3 inch to 56 inch.
Design Pressure: technical up to 35Mpa.
Test Pressure: Hydrotest pressure is 1.3-1.5 times of the design pressure and air-tight test
pressure is the same as the design pressure.
Corrosion allowable: 2mm-3mm or based on customer's requirements.
Seismic intensity: 8 degree.
Applicable medium: crude oil, finished petroleum oil (gasoline,diesel),gas, water.
Option of Pig Signalers available.
Quick Opening Closures with Safety Interlocks.
Third party classification society approved.
Design codes include ASME VIII DIV. I & ASME B31.3, GB150.
