SS 304 Angle Needle Valves, 1/2 Inch, PN320, DN15, FNPT

The SS 304 Angle Needle Valve, manufactured with a stainless steel body, is designed for precise cut-off applications. Sized at 1/2 inch (DN15), it supports a high-pressure rating of Class 2500 LB and PN320. Featuring female NPT ends for secure installation, this valve ensures accurate flow control and reliable performance in demanding environments, making it ideal for systems requiring fine adjustments and efficient shut-off functionality.

Product Name: SS 304 Angle Needle Valve
Type: Angle Type Needle Valve
Body Material: Stainless Steel SS 304
Size: 1/2 Inch, DN15
Pressure: PN320, Class 2500 LB
End Connection: Female NPT (FNPT)
Usage: Cut-off

The angle type internal thread needle valve is designed for long service life and high-temperature resistance. It features vertical movement of the valve tip without rotation, ensuring durability and smooth operation. The valve boasts a beautiful structure and a lightweight feel, making it easy to handle.
Constructed from high-temperature and high-pressure stainless steel, this angle needle valve is a crucial component in instrument measurement pipeline systems. It offers several advantages, including easy installation and disassembly, tight connections, fire prevention, explosion-proof capabilities, high-pressure resistance, and excellent sealing performance.
This valve is ideal for use in power plants, refineries, chemical plants, and instrument measurement pipelines, serving as a reliable flow switch for high-pressure gas and liquid applications. The product's quality is dependable, and we can design and produce various non-standard valves made from special materials to meet user requirements.

Technical Specifications

» Nominal Diameter: DN6-DN100 mm, 1/8-4 Inch
» Nominal Pressure: 1.0 - 42.0 MPa, PN10-PN420
» Main Materials: SS 304, SS 316
» Connection Method: External Threaded/Male Threaded
» Working Temperature: -54°C to 316°C (-65°F to 600°F)

Product Performance

» Low Torque Design: The valve is designed with low torque, making it lightweight and easy to operate.
» Traceable Raw Materials: All raw materials used in the main components are traceable, ensuring quality and reliability.
» Sealing Performance: Equipped with a PTFE or flexible graphite sealing pressure device, the valve ensures no leakage during stem operation.
» Compact and Aesthetic Design: The valve features a compact structure, beautiful appearance, flexible use, tight connection, and excellent sealing performance.
» Easy Maintenance: The valve is easy to install and disassemble, with a secure connection that is beneficial for fire prevention, explosion-proof capabilities, high-pressure resistance, and good sealing performance.
