Carbon Steel Ball Check Valve, A216 WCB, 1 IN, 5000 PSI, NPT

The China Carbon Steel Ball Check Valve Plant offers a high-quality ASTM A216 WCB body valve, designed with a 1-inch (DN25) diameter and capable of withstanding pressures up to 5000 PSI. This valve features a full port design, ensuring minimal pressure drop and maximum flow efficiency. Its NPT threaded ends provide secure and easy connections, making it ideal for a variety of industrial applications.

Product Name: Carbon Steel Ball Check Valve, Full Port
Type: Ball Type Check Valve
Body Material: ASTM A216 WCB Carbon Steel
Size: 1 Inch, DN25
Pressure: 5000 PSI
End Connection: NPT Threaded
Medium: Water, Oil, Gas, etc
Temperature Range: -20°C to 80°C

This ball-type check valve is available in ductile iron, carbon steel, and aluminum bronze, in sizes ranging from 1 inch to 2 inches. Stainless steel balls are standard. Expect an extended life made possible by this valve's patented Hinge-Works feature. The valve is suitable for use in a variety of industrial applications, including hydraulics, pneumatics, pumps, and plumbing. The ball-type check valve is an ideal choice for oil & gas production lines where backflow is a concern. The ball-type check valve offers simplicity and is easily repairable. The function of the check valve is to prevent the backflow of medium in the pipeline.

Technical Specification

» Product: Ball-Type Check Valve
» Size Ranges: NPS 1–2 Inch (DN25–DN50)
» Pressure Range
Ductile Iron: 1000 to 2000 WOG
CS and SS: 2000 to 5000 WOG
» Seat and Seal: Viton
» NACE MR-0175 Compliance
» Threaded Ends: ANSI B1.20.1 (NPT)
» Inspection and Test: API 598

Structural Diagram

Main Parts and Materials

Main Dimensions (mm)
