ASTM B148 C95500 Gate Valve, API 602, 2-1/2 IN, CL800, FNPT

Product Name: ASTM B148 C95500 Gate Valve
Design Standard: API 602
Body Material: Aluminum Bronze ASTM B148 C95500
Size: 2-1/2 Inch, DN65
Pressure: Class 800 LB, PN130
End Connection: FNPT
Operation: Handwheel

Our aluminum bronze gate valves are highly regarded for their exceptional performance in marine engineering, environmental protection, and corrosive medium applications. These valves are specifically designed to withstand harsh working conditions, especially in environments with strong corrosive factors. Known for their outstanding corrosion resistance, particularly in marine and offshore settings, aluminum bronze is the ideal material for ship hardware, seawater pipelines, and other applications that require long-term durability and resistance to corrosion.
Aluminum bronze gate valves are commonly used to shut off media flow, and when fully open, they provide a straight-through flow path, minimizing pressure loss during operation. This design ensures optimal performance in challenging environments while maintaining efficient fluid control.

Technical Specification

» Size Range: 1/2-2 Inch (DN15-DN50) (for Forged Items)
» Design Pressure: Class 150-900 LB (PN10-PN160)
» Materials: Aluminum Bronze ASTM B148 C95400, C95500, C95800, ASTM B150 C63000, C63200
» End Connections: FNPT, RF, Integral Flanged Ends
» Design and Manufacture: ASME B16.34, API 602
» Face to Face (End to End): ANSI B16.10
» Flanged Connection: ANSI B16.5
» Test and Inspection: API 598, API 6D
» Threaded Ends: ASME B1.20.1
» Temperature Range: -29°C to 260°C
» Medium: Sea Water, Offshore and Marine

Product Features

» OS&Y (Outside Stem and Yoke) Design
» Optional Locking Device or Stem Extension
» Optional Bolted Bonnet
» Optional Direct Mounting to ISO 5211
» Available in Full Bore or Reduced Port
» Metal-Sealed for Enhanced Durability
