ASTM A890 5A Butterfly Valve, API 609 CAT.B, 10 Inch, CL300

Product Name: ASTM A890 5A High Performance Butterfly Valve
Design Standard: API 609 Category B
Body Material: ASTM A890 5A
Size: 10 Inch, DN250
Pressure: Class 300 LB, PN50
End Connection: Lug

The fire-safe high performance butterfly valve is engineered with two distinct seats to ensure optimal functionality. The primary seat material is RPTFE (Reinforced Poly Tetra Fluoro Ethylene), which enables the valve to achieve a tight shut-off, effectively preventing any leakage. This soft seat material not only offers excellent sealing properties but also enhances the valve's overall performance. Additionally, the valve is equipped with a fire-safe seat made of metal. This secondary seat provides enhanced resistance to high temperatures and can withstand the rigorous conditions of a fire incident. The combination of the RPTFE soft seat and the fire-safe metal seat guarantees reliable performance in both normal and emergency situations, making this valve an ideal choice for applications where safety and efficiency are paramount.

Technical Specification

» High Performance Butterfly Valve
» Design: Bi-Eccentric
» Normal Size Range:
   Class 150 LB: 2-60 Inch
   Class 300 LB: 2-48 Inch
   Class 600 LB: 2-24 Inch
» Normal Pressure Rating: Class 150-600 LB, PN10–PN40, 10K–20K
» Standard: API 609 Category B
» Body: ASTM A351 CF8, CF8M, CF3, CF3M, A890 4A, 5A, 6A
» Disc: ASTM A351 CF8, CF8M, CF3, CF3M, A890 4A, 5A, 6A
» Seat: 316L + RPTFE
» Shaft: 17-4PH
» Shutoff Rating: Class VI, Bubble Tight
» Operation: Handle, Worm Gear, Pneumatic, Electric
» Temperature Range: Soft Seat: -29°C to 150°C
» Medium: Water, Gas, Oil, etc.

Application Scope

» Chemical and Petro-Chemical
» Liquified Gas
» Refrigeration
» Heavy Industrial
» Power and Co-Generation Plants
» Steel and Iron Works
» Pulp and Paper Mills
» Oil Refineries and Oil Fields
» Ship Building
» Hydrocarbon Processing
» Gas Piping
» Local Area Energy Supply
» Industrial Construction
» Marine
