ASTM A351 CF3M Globe Valve, ASME B16.34, 6 Inch, 600 LB, RF

The ASTM A351 CF3M Globe Valve is a high-performance valve designed for precise flow control in demanding applications. Manufactured with a stainless steel body, it meets ASME B16.34 standards and features a 6-inch, DN150 size with a Class 600 LB, PN100 rating. The valve is equipped with RF flanged ends for easy installation and manual operation for reliable, user-controlled functionality. This globe valve ensures durability, corrosion resistance, and efficient operation in a variety of fluid handling systems.

Product Name: ASTM A351 CF3M Globe Valve
Design Standard: ASME B16.34
Body Material: ASTM A351 CF3M
Size: 6 Inch, DN150
Pressure: Class 600 LB, PN100
End Connection: RF Flanged
Operation: Manual

Cast Steel Globe Valves are engineered and manufactured to achieve less than 100 ppm (parts per million) leakage of volatile organic compounds (VOCs). Extensive baseline laboratory testing, including both static and cycle tests, has been conducted to establish the critical design parameters required for low emission sealing, specifically in the stem packing and bonnet gasket seal areas. An in-house testing procedure has been developed and is regularly performed to ensure that the standard product design and manufacturing criteria consistently result in Cast Steel Globe Valves meeting the maximum VOC leakage limit of 100 ppm prior to shipment.

Technical Specifications

» Nominal Diameter: NPS 1/2–24 Inch (DN15–DN600)
» Design Pressure: Class 150–2500 LB (PN10–PN420)
» Materials: ASTM A216 WCB, WCC, A217 WC6, WC9, C5, C12A, A352 LCB, LCC, A351 CF8, CF8M, CF3M, CF8C, CN3MN, CK3MCUN, CN7M, A890 4A (CD3MN), 5A (CE3MN), 6A (CD3MWCuN), B148 C95800, C95500
» End Connections: Flanged (FF, RF, RTJ) and BW to international standards
» Operation: Handwheel, bevel gear, electric, pneumatic
» Applications: Electric power, petroleum refining, petrochemical engineering, offshore oil, urban water engineering, chemical engineering
» Design and Manufacture: ASME B16.34, BS 1873, DIN 3356
» Face to Face (End to End): ANSI B16.10, EN 558 series
» Flanged Connection: ANSI B16.5, EN 1092 series
» Butt Welded End: ANSI B16.25
» Test and Inspection: API 598, ISO 5208, EN 12266-1
» Temperature Range: -29°C to 595°C
» Medium: Water, gas, oil, and other fluids

Product Features

» OS&Y design with a bolted bonnet and rising stem
» Short stroke for quick and easy open/close operation
» Suitable for large sizes and high pressures with a relief cone (internal bypass)
» Disc sealing options: flat sealing or throttle cone (regulating disc)
» Body seat options: threaded seat or welded seat
» OS&Y (Outside Stem and Yoke) configuration
» Metal-sealed trims available (API Trim #1, #5, #8, #10, etc.)
» Optional locking device or stem extension
» Optional direct mounting to ISO 5211 standard
» Reduced port
