ASTM A216 WCB Wedge Gate Valve, API 600, 4 IN, CL150, OS&Y

Product Name: ASTM A216 WCB Wedge Gate Valve, OS&Y
Design Standard: API 600
Body Material: ASTM A216 WCB
Size: 4 Inch, DN100
Pressure: Class 150 LB, PN20
End Connection: Flanged
Operation: Handweel

Cast Steel Gate Valves are engineered to ensure minimal leakage, with a strict limit of less than 100 ppm (parts per million) of volatile organic compounds (VOCs). These valves undergo extensive baseline laboratory testing, including static and cycle tests, to establish the necessary design parameters for achieving low-emission sealing in both the stem packing seal and bonnet gasket areas. A comprehensive in-house testing procedure is regularly performed to ensure that the standard product design and manufacturing criteria consistently meet the required VOC leakage standards before shipment.

Technical Specifications

» Nominal Diameter: NPS 1/2-48 Inch (DN15-DN1200)
» Temperature Range: -29°C to 595°C
» Medium: Water, gas, oil, etc.
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Materials: ASTM A216 WCB, WCC, A217 WC6, WC9, C5, C12A, A352 LCB, LCC, A351 CF8, CF8M, CF3, CF3M, CF8C, CN3MN, CK3MCUN, CN7M, A890 4A (CD3MN), 5A (CE3MN), 6A (CD3MWCuN), B148 C95800, C95500
» End Connections: Flanged (FF, RF, RTJ) to international standards
» Operation: Hand wheel, bevel gear, electric, pneumatic
» Design and Manufacture: ANSI B16.34, API 600, API 6D, API 603, BS 1414
» Face to Face (End to End): ANSI B16.10, API 6D
» Flanged Connection: 2-24 Inch to ANSI B16.5, 22 Inch, 26-36 Inch to MSS-SP-44 or to API 605 on request
» Test and Inspection: API 598, API 6D
» Butt Welded End: ANSI B16.25

Product Features

» Anti-Friction Ball Thrust Bearing: Reduces friction between mating parts for smooth and efficient operation.
» Grub Screw: Secures the yoke nut in place within the bonnet for enhanced stability.
» Grease Nipple: Facilitates lubrication of mating parts, ensuring continuous smooth movement.
» OS&Y (Outside Stem and Yoke): A design feature that keeps the stem outside the valve body for easier maintenance and operation.
» Metal-Sealed: Available in API Trim #1, #5, #8, #10, providing reliable sealing performance.
» Optional Locking Device or Stem Extension: Enhances safety and accessibility, depending on application requirements.
» Optional Direct Mounting to ISO 5211: Allows for direct actuator mounting, streamlining installation.
» Full Port: Offers an unrestricted flow path for maximum capacity and efficiency.
