API 609 Category B Butterfly Valve, C95800, 6 IN, CL150, Lug

Name: API 609 Category B Butterfly Valve, C95800, 6 IN, CL150, Lug
SKU: KV-20250107-HPBV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The API 609 Category B Butterfly Valve features a double offset design, offering superior sealing and performance. Made from bronze ASTM B148 C95800, this 6-inch, DN150 valve is rated for Class 150 LB and PN20 pressure. With lug ends and gear operation, it provides secure installation and precise control in a wide range of industrial applications.

Request a quote

Detail Information

Product Name: High Performance Butterfly Valve, Double Offset
Design Standard: API 609 Category B
Body Material: Bronze ASTM B148 C95800
Size: 6 Inch, DN150
Pressure: Class 150 LB, PN20
End Connection: Lug
Operation: Gear

The double offset high-performance butterfly valve in bronze is a versatile and durable valve designed for a wide range of applications. It features a bi-directional design and a blow-out proof shaft, ensuring reliable performance even under extreme conditions. The valve can be customized with various seat options, including soft seats, metal seats, and fire-safe seats, based on specific customer requirements. This flexibility enhances functionality and compatibility with diverse industries and environments. With its robust construction and customizable features, the flanged double offset high-performance butterfly valve in bronze provides a reliable solution for efficient flow control and is widely used across various industrial sectors.

Technical Specifications

» Type: Double Offset
» Size Range:
Class 150 LB: 2-48 Inch
Class 300 LB: 2-48 Inch
Class 600 LB: 2-24 Inch
» Pressure Rating: Class 150-600 LB, PN10-PN40, 10K-20K
» Standard: API 609 Category B
» Body Material: Aluminium Bronze (ASTM B148 C95800, C83600, B584 C84400, ASTM B62)
» Disc Material: Aluminium Bronze (ASTM B148 C95800, C83600, B584 C84400, ASTM B62)
» Shaft Material: MONEL K500
» Shutoff Rating: Class VI, Bubble Tight
» Certifications: API 607, PED
» Unique Valve Seat Design
» Optional Seatings: RTFE
» Operation Options: Handle, Worm Gear, Pneumatic, Electric
» Temperature Range:
Soft Seat: -29°C to 260°C
Metal Seat: -51°C to 550°C
Metal Seat (Cryogenic): -196°C to 121°C
Fire Safe Seat: -51°C to 550°C
» End Connections: Wafer, Lug, RF Flange
» Medium: Sea Water, etc.

Application Scope

» Chemical/Petrochemical
» Liquefied Gas/Refrigeration
» Heavy Industrial
» Power/Co-Generation Plants
» Steel and Iron Works
» Commercial
» Pulp and Paper Mills
» Oil Refineries and Oil Fields
» Shipbuilding
» Hydrocarbon Processing
» Gas Piping
» Local Area Energy Supply
» Construction
» Marine
