API 602 Lift Check Valve, ASTM A105N, 2 IN, CL300, DN50, RF

Product Name: Forged Lift Check Valve
Design Standard: API 602
Body Material: ASTM A105N
Size: 2 Inch, DN50
Pressure: Class 300 LB, PN50
End Connection: RF Flanged

Forged Steel Check Valves are designed and manufactured in strict compliance with international standards such as API 602, ASME B16.34, or equivalent. These valves are engineered to minimize flow resistance and pressure drop, ensuring efficient performance. They are specifically designed for horizontal installation only. The lapped and screwed seat ring guarantees a tight shutoff and long service life. The valve's disc is precisely designed, accurately machined, and guided for reliable automatic shutoff at zero pressure. These valves feature a compact structure and low emission service, available in both swing and piston constructions.

Technical Specifications

» Size Range: 1/2-2 Inch for forged items (DN15-DN50)
» Design Pressure: Class 150-2500 LB (PN10-PN420)
» Materials: Forged Carbon Steel, Alloy Steel, Stainless Steel, Duplex Steel (ASTM A105N, A350 LF2, A182 F11, F22, F304, F304L, F316, F316L)
» Trim Materials: 13% Cr, ASTM A182 F11, F22, SS 304, SS 304L, SS 316, SS 316L, and other special materials
» End Connections: SW, FNPT, BW, RF, RTJ, Grooved
» Design and Manufacture: ASME B16.34, API 602
» Face-to-Face (End-to-End): ANSI B16.10
» Flanged Connection: ANSI B16.5
» Test and Inspection: API 598, API 6D
» Butt-Welded End: ANSI B16.5
» Threaded Ends: ASME B1.20.1
» Socket-Weld Ends: ASME B16.11
» Temperature Range: -29°C to 595°C
» Medium: Water, gas, oil, etc.

Product Features

» The lifting check valve helps reduce water hammer during the flow of liquid media, protecting equipment and pipelines from impact damage.
» Available in two bonnet designs: Bolted Bonnet and Welded Bonnet.
» Options for both Swing Type and Lift Type configurations.
» Offered in Full Port or Reduced Bore versions.
