Jacket Gate Valve, DIN 3352, GS-C25, DN100, PN40, Flange, Handwheel
Model Number: GV 54
Key Specifications / Features
China Jacket Gate Valve Manufacturer Kelly Offers Jacket Gate Valve, DIN 3352 Standard, GS-C25 Material, DN100, Pressure PN40, Flange End, -29℃~+425℃.
Detail Information
Valve description:
Design standard: DIN 3352.
Body material: GS-C25.
Nominal diameter: DN100.
Pressure: PN40.
End connection: Flange.
Face to face: EN558-1.
Working temperature: -29℃~+425℃.
Mode of operation: Handwheel.
Test and inspection: DIN3230, EN12266-1.
Product Range:
Body Material: Carbon steel, Stainless steel, Alloy steel.
Normal diameter: 1/2"~60" (DN15~DN1500).
End connection: BW, Flanged.
Pressure range: 150lbs~2500lbs (PN16~PN420).
Operation: Handwheel, Gearbox, Electric, Pneumatic, Electro hydraulic actuator, Gas over oil actuator.
Working temperature: -196℃~+570℃.
Design standard: DIN 3352.
Body material: GS-C25.
Nominal diameter: DN100.
Pressure: PN40.
End connection: Flange.
Face to face: EN558-1.
Working temperature: -29℃~+425℃.
Mode of operation: Handwheel.
Test and inspection: DIN3230, EN12266-1.
Product Range:
Body Material: Carbon steel, Stainless steel, Alloy steel.
Normal diameter: 1/2"~60" (DN15~DN1500).
End connection: BW, Flanged.
Pressure range: 150lbs~2500lbs (PN16~PN420).
Operation: Handwheel, Gearbox, Electric, Pneumatic, Electro hydraulic actuator, Gas over oil actuator.
Working temperature: -196℃~+570℃.
