Inverted Pressure Balanced Lubricated Plug Valve, API 6D, A105

Name: Inverted Pressure Balanced Lubricated Plug Valve, API 6D, A105
SKU: Kelly-PLV-20241108-03
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 3/4-inch 150 LB inverted pressure-balanced lubricated plug valve is designed according to the API 6D standard, with a valve body made of ASTM A105. Featuring an inverted oil seal, body valve seat, and a structural length of 130mm, this valve ensures reliable sealing and smooth operation. It uses RF (raised face) connections and lever operation, offering ease of control. This robust design makes it ideal for applications requiring efficient flow regulation and durability.

Request a quote

Quick Detail

Type	Lubricated Plug Valve
Size	3/4 Inch, DN20
Pressure	Class 150 LB, PN20
Connection	RF
Operation	Lever
Body Material	ASTM A105
Design Norm	API 6D
Face to Face Dimension	Customer-specified
Flange Dimension	ASME B16.5
Pressure-Temperature	ASME B16.34
Fire Safe	APl 6FA
Test & Inspection Code	API 6D
Temperature	≤ 80°C
Applicable Medium	Water, Oil and Gas

Detail Information

Inverted Pressure Balanced Lubricated Plug Valve, API 6D, 3/4 Inch, 150LB, ASTM A105 Body.

Features

1. Lubricating oil reduces friction between the valve core and seat, ensuring smoother operation and making it ideal for applications requiring frequent valve cycling.

2. The unique sealing design of the inverted oil-sealed plug valve makes it suitable for a wide range of media, including water, oil, gas, and media containing particles or impurities.

Technical Drawing
