ASTM A352 LCC Swing Check Valve, API 6D, 14 Inch, 600 LB

Name: ASTM A352 LCC Swing Check Valve, API 6D, 14 Inch, 600 LB
Brand: www.kellyvalve.com
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

ASTM A352 LCC Swing Check Valve Provider: ASTM A352 LCC Non-Return Check Valves, BB, Swing Type Disc, API 6D, 14 Inch, Class 600 LB, Flanged Ends.

14 Inch Check Valve ASTM A352 LCC Check Valve Class 600 LB Check Valve API 6D Check Valve Swing Type Check Valve Flanged Check Valve BB Check Valve Non Return Check Valve

Type	Non-Return Valve (Check Valve)
Nominal Size	14 Inch
Nominal Pressure	600 LB
Construction	BB, Swing Type Disc
Connection	Flange
Design & Manufacture	API 6D
End to End	ASME B16.10
Connection	ASME B16.5
Test & Inspection	API 598
Body Material	ASTM A352 LCC
Applicable Temp	-48℃ - 345℃
Media	W.O.G.

Features
1. Bonnet and disc design gives easy access to maintenance Lip sealing on the disc ensures tightness.
2. A lightweight disc just requires a minimum of force to open and close the valve.
3. The disc is able to move slightly both horizontally and vertically to close completely tight.
4. Full bore ensures low head loss.
