ASME B16.34 Y Strainer, 2 Inch, 150 LB, ASTM A216 WCB, RF

Name: ASME B16.34 Y Strainer, 2 Inch, 150 LB, ASTM A216 WCB, RF
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

2 Inch 150 LB Y type strainer is made according to ASME B16.34 standard. The valve body is made of ASTM A216 WCB. It has the structural characteristics of Y-shaped. Its connection mode is RF.

Request a quote

Quick Detail

Product Description

Type	Y Type Strainer
Size	2 Inch
Pressure	150 LB
Connection	RF
Body Material	ASTM A216 WCB
Design Norm	ASME B16.34
Face to Face Dimension	ASME B16.10
Flange Dimension	ASME B16.5
Test & Inspection Code	API 598
Temperature	-29 - 425°C
Applicable Medium	Water, Oil and Gas

Detail Information

2 Inch 150 LB Y Type Strainer RF WCB ASME B16.34

Features

1. Easy to disassemble and clean. Regular inspection and cleaning of the filter screen can ensure the normal operation of the equipment and extend the service life of the filter;

2. Internally equipped with a filter screen or filter element, used to capture solid particles, impurities, or other unwanted substances in the fluid. This helps to protect subsequent equipment, pipelines, and valves from particle damage.

Technical Drawing
