API 608 Floating Ball Valve, 1-1/2 Inch, 1000 WOG, BW

Name: API 608 Floating Ball Valve, 1-1/2 Inch, 1000 WOG, BW
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

1-1/2 Inch 1000 WOG floating ball valve is made according to API 608 standard. The valve body is made of ASTM A182 F304. It has the structural characteristics of full bore, floating ball and three-piece. Its connection mode is BW. It has a lever operation mode.

Request a quote

Quick Detail

Product Description

Type	Floating Ball Valve
Size	1-1/2 Inch
Pressure	1000WOG
Connection	BW
Operation	Lever
Body Material	ASTM A182 F304
Design Norm	API 608
End to End Dimension	Manufacture Standard
BW End	ANSI B16.25
Fire Safe Test	API 607
Test & Inspection Code	API 598
Temperature	-29 - 150°C
Applicable Medium	Water, Oil and Gas

Detail Information

Forged Steel, 1-1/2 Inch 1000 WOG Floating Ball Valve, API 608, Lever, BW, Body

Features

1. In order to adapt to special working conditions (such as flammable and explosive media), the floating ball valve can be designed as an anti-fire and anti-static type to ensure the safe operation of the system;
2. Simple structure, few components, low maintenance requirements, reduced maintenance workload and downtime.

Technical Drawing
