API 594 Dual Plate Check Valve, 3 IN, 150 LB, ASTM A216 WCB

Name: API 594 Dual Plate Check Valve, 3 IN, 150 LB, ASTM A216 WCB
Brand: www.kellyvalve.com
SKU: Kelly-CV-20240810-02
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: Kelly-CV-20240810-02

Key Specifications / Features

The 3-Inch CL150 Wafer Check Valve is manufactured in compliance with the API 594 standard, ensuring reliability and performance. The valve features a robust A216 WCB body with 13Cr trim, providing excellent durability and corrosion resistance. Designed with a dual-disc structure, it offers efficient flow control and minimizes pressure drop. The wafer-style connection allows for easy installation between flanges, making it a versatile choice for various industrial applications.

API 594 Check Valve 3 Inch Check Valve ASTM A216 WCB Check Valve Class 150 LB Check Valve Dual Plate Check Valves

Detail Information

API 594 Dual Plate Check Valve, 3 IN, 150 LB, ASTM A216 WCB Body, Wafer Type.

Features

1. The overall structure is simple, compact, aesthetically pleasing, with a long service life and high reliability;

2. Lightweight, fast closing of valve disc, low water hammer pressure, suitable for both horizontal and vertical pipelines.
