Hanger Shot Blasting Machine for Steel Furniture

Steel Furniture Shot Blasting Machine Company JX Offers Hanger Type Shot Blasting Machine for Steel Furniture in Metal Working for Surface Finishing.
It is made for increasing roughness of surface and shot peening to raise fatigue strength.

Main Technical Parameter:
1. Size of Blasting Jobs:
Max. Size for workpiece (diameter*height) Ф1100×1200mm.
2. Blast nozzles(2 set) diameter of impeller: ф250 mm.
Max.volume for blasting: 2×180kg/min.
Power: 2×11kw.
3. Lifting Hook:
(double) Max. hangering weight: 1000kg.

If you're interested in our style machine, welcome to contact us to get more detailed info.

This machine is not a standard machine, any parameters can be customized according to clients' requirements, so any further information please contact with us, our skilled engineer team will give you the most professional and cost-effective solutions.

Machine Details:




These Type of Machines Consist of Under Mentioned Parts:
1. Main Blast Cabinet with inspection Door
2. Blast Wheel Units with Drive Mechanism.
3. Abrasive circulation unit
4. Bucket Elevator unit
5. Abrasive Separation/Cleaning system with Storage Hopper
6. Dust Collector with Cleaning Mechanism.
7. Roller Conveyor system at Inlet & Outlet Side.
8. Control Panel with PLC Control System.

JX Shot Blasting Machine offers upgraded transport technology, high-efficient blast wheels and multiple machine sizes and types adhere to the customer’s shot-blasting needs. If you have special requirements, please download Blasting Equipments Questionnaire for your reference.
