8x4 Dump Truck, Tipper Truck, 12170 kg, GVM 25000 kg, Load 12700 kg
Model Number: JS-SV-02
Key Specifications / Features
Justsun Provides New 8x4 Tipper Truck, 8x4 Dump Truck for Sale. Custom-built 8x4 Commercial Tippers with Kerb Weight 12170 kg, GVM 25000 kg (25 Ton), Rated Load Capacity 12700 kg (12.7 Ton), Max Speed 79 km/h - 83 km/h. Howo Quad Axle Truck Ideal for Longer and Heavier Loads with the Most Competitive Prices. Contact Today!
Detail Information
HOWO 8*4 DUMP TRUCK
SPECIFICATION
Other types of pump trucks can also be customized. Please contact for more.
SPECIFICATION
| Kerb weight (vehicle/chassis) kg | 12170/8630 | 12170/8630 |
| Gross Mass kg | 25000 | 25000 |
| Rated load kg | 12700 | 12700 |
| Complete vehicle overall dimensions (length×width×height) mm | 7545x2496x3170 | 7545x2496x3170 |
| Chassis overall dimensions(length×width×height) mm | 6790×2496×2958 | 6790×2496×2958 |
| Wheelbase mm | 3225+1350 | 3225+1350 |
| Front/rear overhang (vehicle/chassis) mm | 1500/(1470/715) | 1500/(1470/715) |
| Wheel track (front/rear) mm | 2041/1830 | 2041/1830 |
| Minimum ground clearance mm | 314 | 314 |
| Approach/departure angle(vehicle/chassis) ° | 19/(30/65) | 19/(30/65) |
| Maximum speed km/h | 79 | 83 |
| Max gradeability % | 20 | 20 |
| Minimum turning diameter m | 15 | 15 |
Other types of pump trucks can also be customized. Please contact for more.
