Carbon Steel Lift Check Valve PN40 DN150 DIN Standard
Key Specifications / Features
China Check Valve Manufacturer JONLOO supplies carbon steel lift check valve. The valve is made according to DIN standard. Most European countries would have DIN standard valves for their piping system. JONLOO valves is CE certified and serves well for the piping.
Contact Supplier
Detail Information
Details:
Size: DN150
Pressure: PN40
Body/Bonnet: A216 WCB
Disc:A216 WCB+13Cr
Seat: A105+13Cr
Bolted Bonnet Design
Standards:
Design and Manufacture:EN 1868
Face to face: DIN 3202
Flanged ends: EN 1092-1
Inspection and test： EN 12266-1
Features:
Lift type
Bolted bonnet
Anti-rotation disc
Renewable seat ring
Non-penetrate disc shaft
Horizontal service
Size: DN150
Pressure: PN40
Body/Bonnet: A216 WCB
Disc:A216 WCB+13Cr
Seat: A105+13Cr
Bolted Bonnet Design
Standards:
Design and Manufacture:EN 1868
Face to face: DIN 3202
Flanged ends: EN 1092-1
Inspection and test： EN 12266-1
Features:
Lift type
Bolted bonnet
Anti-rotation disc
Renewable seat ring
Non-penetrate disc shaft
Horizontal service
Supplier Information
Shanghai Jonloo Machine MFG Co., Ltd.
Verified Supplier
No 48, Jian'an Road, Xingta Industrial Zone, Fengjin Town, Jinshan, Shanghai, China/Linpu Road, Zhangbao Industrial Zone, Yongjia Oubei, Wenzhou City, Zhejiang
Est.
Certifications:
jo*******02
1150 article(s)
Comments
Leave a Comment
Related Products
Lift Check Valve DN25 PN100 CF8 Material
Shanghai Jonloo Machine MFG Co., Ltd.
Carbon Steel Ball Valve LC3 Material for Low Temperature Service
Shanghai Jonloo Machine MFG Co., Ltd.
Carbon Steel Ball Valve DIN Standard PN16 DN40
Shanghai Jonloo Machine MFG Co., Ltd.
Carbon Steel Globe Valve with Handwheel PN16 DN125 WCB DIN 3356
