12“ CL300 RF DUAL PLATE CHECK VALVE LCC BODY AND PLATE FACE TO FACE: 440MM
Key Specifications / Features
China Check Valve Factory JONLOO supplies Flange ended Dual Plate Check Valve, also called dual check valve. The valve is available in wafer type, lug type and flange type. Pls contact JONLOO if you need.
Detail Information
Details
Size: 12 Inch.
Pressure: 300 LB.
Body: LCC
Disc: LCC
Seat: 316L
Spring: ASTM B637 UNS N07718
FACE TO FACE: 440MM
Size: 12 Inch.
Pressure: 300 LB.
Body: LCC
Disc: LCC
Seat: 316L
Spring: ASTM B637 UNS N07718
FACE TO FACE: 440MM
Features
1.Tightened Pin structure.
2.Wafer end & Dual Plate design.
3.Dual Plate With Spring Loaded structure
4.Application: Chemical processing, Oil Field & Power Plant, Hydrocarbon processing
Standards
1.Design&Mamufacture: API 594, API 6D
2.Face-to-face API 594, API 6D, DIN 3202
3.Flange end: DIN2543-2548, API605, ASME B 16.47, ANSI B 16.5
4.Inspection and test: API 598
5.Special: NACE MR-01-75
