HMI Operation Sanitary Napkin Production Line for Hot Sale

Name: HMI Operation Sanitary Napkin Production Line for Hot Sale
SKU: HM-231031-SNM-03
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Our Hot Sale Sanitary Napkin Production Line from China is a top-performing manufacturing solution for sanitary napkins. It boasts HMI (Human-Machine Interface) operation and a PLC (Programmable Logic Controller) control system, making it easy to operate and control the production process.

Request a quote

Detail Information

HMI Operation Sanitary Napkin Production Line for Hot Sale

Subject	Parameter
Overall size(LWH)	30M6M3M(For reference only)
Machine size(LWH)	22m2m2.5m,based on the product provided by client
Design speed	600pcs/min
Stable speed	500pcs/min
Pass precentage	98%
Work efficiency	90%
Power source	380V,50HZ,(3phase,4lines+ground wire)
Machine capacity	about 180KW
Air pressure	0.6-0.8Mpa
Machine weight	About 50T
Machine color	Customized

Configuration:

1. Product structure:
Topsheet, ADL(Blue core layer), Layer tissue,fluff pulp (mix with SAP) / SAP paper, back sheet, wings/back release paper.

2. Product size:
Daytime use: 240mm Night use: 285mm(Customized)

3. Control system:
PLC programming control, HMI operation.

4.Tension system:
Carrier tissue, absorbent paper, topshee NW, leg cuffs NW, ADL, PE film, back release paper, Wings release paper, pouch fillm, A&B shaft active unwinding by inverter motor.

5.Drive system:
Single-axle gear, imported timing belt, key position adopt the imported bearing.

6.Safety system:
Safty guard installed at the operating side, equipped with emergency stop switch, security identifier. Driven side is equipped with sadety pull wire.

7.Materials corrective system:
Germany BST automatic web guide system (optional)

Main Product:

1. Baby diaper Production Line( Include:I & T shape diaper,Baby pants,Full Elastic waistband diaper)
2. Adult diaper Production Line(Include:Adult diaper,Adult pants)
3. Sanitary Napkin & Panty Liner Production Line
4. Menstruation Panty Production Line
5. Under Pad Production Line
6. Disposable Breast Pad Production Line
