640kW Container Generator, Perkins Engine, 50Hz, Water Cooled

Name: 640kW Container Generator, Perkins Engine, 50Hz, Water Cooled
SKU: GGS-240321-CGS-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Introducing our Containerized Perkins Powered Diesel Generator, delivering a prime power of 640kW (800kVA) at a frequency of 50Hz. Equipped with a reliable 4-stroke, 6-cylinder engine, this generator ensures efficient performance. Trust in our generator for reliable and robust power supply in various applications.

Request a quote

Detail Information

Product Name: 640kW Container Generator
Model: GGS-800-P
Prime Power: 640kW, 800kVA
Frequency: 50Hz
Rated Voltage: 400V
Engine: Perkins 4006-23TAG3A, 4 Stroke, 6 Cylinder in Line
Alternator: Stamford HCI634G, Brushless, Self-excited
Other Feature: 3 Phase, Water Cooled, Diesel Fuel

Technical Data

Generator Specification
Generator Model	GGS-800-P
Frequency	50Hz
Prime Power	640kW/800kVA
Standby Power	720kW/900kVA
Rated Voltage	400V (Available with custom requirements)
Dimension (L x W x H) (mm)	20FT Container
Net Weight (KG)	8200
Engine Specification
Engine Brand	Perkins
Engine Model	4006-23TAG3A
Prime Power	705kW
Standby Power	786kW
Cooling System	Water Cooled
Aspiration	Turbocharged
Number of Cylinders	6 Cylinder in Line
Cycle	4 Stroke
Displacement	22.92 L
Bore x Stroke	160 x 190 mm
Compression Ratio	13.6:1
Rated Speed	1500 RPM
Governor type	Electronic
Alternator Specification
Alternator Brand	Stamford
Alternator Model	HCI634G
Excitation system	Brushless, Self-excited
Number of phase	3 Phase
Power Factor	0.8
Protection Grade	IP23
Insulation Class	H
